Power Supply

■ Power via PSE Device or Power Adapter
Some APs can be powered via the power adapter or the PSE device (such as a
PoE switch) which complies with Power Source Class 2 (PS2) or Limited Power
Source (LPS) of IEC 62368-1�
Note: Availability depends on the actual product� Please refer to the product specifications�
Via PoE Switch
PoE Switch
Via Power Adapter
Power Adapter
■ Power via PoE Adapter
Some APs can be powered via the PoE adapter�
Note: Availability depends on the actual product� Please refer to the product specifications�
3
PoE Adapter Switch
PoE LAN
1
2
