Chapter 3 Cleaning and
Maintenance
Notes:
1.HEPA filter,brushroll and cleaning solution are
available at distributors.
2.It is recommended to clean the dirty water tank in
time after use; When the amount of dust is too much
resulting in HEPA blocked, it is necessary to clean
HEPA, if necessary, HEPA can be replaced; After a long
time of use, the brushroll may entangle with hair and
other long subjects, which needs to be cleaned in time.
Dirty water tank cleaning
1.When dirty water tank is full, the dirty water tank full
indicator on LED screen will blink.The machine will stop
working immediately and has voice reminding "Dirty
water tank full, please empty tank".
2.After turning off the vacuum cleaner, remove the dirty
water tank, lift the water tank top cover, and remove the
foam filter frame from it, open the flip cover of the foam
filter frame, take out the foam filter. Pour out dirty water
and dirt in the water tank, then wash dirty water tank,
water tank cover, foam filter frame and foam filter. (Fig 15)
3.If there is foreign matter in the dirty water tank pipe, it
can be cleaned with the cleaning brush.
4.Dry the above parts after washing. And then reassemble all the parts back into dirty water tank.
Notes:
1.When the machine is not in use, the upper cover of dirty water tank should be taken out for airing to avoid
odor.
2.After the machine has finished working, it is recommended to clean the dirty water tank immediately to avoid
odor. (Fig 16)
3.After cleaning the upper cover of the dirty water tank, the metal contact sheet on the top cover of the dirty
water tank must be wiped dry before use
Floorhead cleaning
Take out the brushroll window and pull out the brushroll. Use dry cloth to wipe brushroll housing and remove
the hair tangled around brushroll by the blade. Wash the brushroll window and brushroll in clean water. After
cleaning, assemble brushroll and brushroll window back to machine(The brushroll can also be put into the
accessories holder for drying).(Fig 17)
Notes:
1.Do not wash the whole floorhead in water or under tap water. Do not wash the floorhead in water or under
tap water after pulling out the brushroll. Do not use tap water to wash the air path of the floorhead after taking
of clean water tank. So as not to damage the components and affect the use.
2.If the cleaner will not be used soon after cleaning,completely dry the dirty water tank, dirty water tank cover,
filter, filter frame, brushroll, brushroll window, machine and then assemble the machine for storage, in order to
prevent the bacteria from breeding in the humid environment and producing odor.
Dust sensor cleaning
When the voice remind "Please clean the air path and filter", remove the dirty water tank. Check whether
there are large particles blocking the pipe of floorhead first. Second, check whether the dust sensor located
inside air path is covered by dirt. Then wipe the inner wall of the pipe with mop or cleaning brush provided. (Fig 18)
8
15
16
Dirty water tank
cleaning
17
HEPA filter
cleaning
18
