S E T T I N G U P YO U R ZOTAC Z B OX N A N O
1. Connecting antenna for Wi-Fi
2. Connecting to a wired home network
3. Connecting USB 2.0 devices
4. Connecting USB 3.0 devices
5. Connecting a DisplayPort display
6. Connecting an HDMI display
7. Connecting the power adapter and turning on
the system
F R O N T PA N E L
1. Power button
2. Power LED
3. SATA LED
4. Memory card reader (SD/SDHC/SDXC)
5. Headphone/Audio Out jack
6. Microphone jack
7. USB 3.1 Type-C
8. USB 3.0 port
R E A R PA N E L
1. WiFi antenna connector
2. LAN (RJ45) ports
3. USB 3.0 ports
4. USB 2.0 ports
5. DisplayPort
6. HDMI port
7. Power input (DC19V)
1
2
3
4 5
5
4
1
2 3
2
2
1
3 4 3
7
6
6
8
7
5
7
6
3
