Constant-Lighting Control - STEINEL 3000er Serie Applikationsbeschreibung

Name Settings
Day night parameters
Day/night switchover inactive
active
When day/night switchover is activated, the parameter setting can be
switched over via an input object.
ON level in percent (only 0 %...100 %
for General parameters:
Object light output ->
dimming level)
This parameter is used to select which dimming level to send for the ON
state.
OFF level in percent (only 0 %...100 %
for General parameters:
Object light output ->
dimming level)
This parameter is used to select which dimming level to send for the OFF
state.
1...64
Switch ON scene
(only for General param-
eters: Object light output
-> scene)
This parameter is used to select which scene to send for the ON state.
Switch OFF scene (only 1...64
for General parameters:
Object light output ->
scene)
This parameter is used to select which scene to send for the OFF state.
Daytime operation Yes
No
Setting to define whether light output is to be switched irrespective of light
level.
Switching threshold ON 2 lux...1000 lux
This parameter is used to select the light level and detected presence from
which to switch the light output ON.
Switch OFF in relation to Yes
light level
No
This parameter is used to switch OFF the light output in relation to ambient
light level in spite of someone being present.
Offset switching thresh- 10 lux...1000 lux
old OFF
This parameter is used to select the offset from which to switch the light
output OFF.
Light output stay-on time hh:mm:ss
Stay-ON time is started if no presence is detected. This has the purpose of
preventing the output from switching OFF immediately if the room is only
vacated for a short time and having to be switched back ON again when a
person returns to the room.
Stay-ON time can be set from 00:00:10 to 18:12:15.
Basic illumination dim- 1 %...100 %
ming level (for basic
illumination only: basic
illumination -> active
and basic illumination:
basic illumination ON ->
time-limited, in relation
to ambient light level and
always)
This parameter is used for setting the dimming level at which basic illumina-
tion is switched ON.
Basic illumination 2 lux ...1000 lux
threshold level (for basic
illumination only: basic
illumination -> active
and basic illumination:
basic illumination ON ->
time-limited, in elation to
ambient light level and
always)
This parameter is used for setting the threshold at which basic illumination is
activated if the threshold is not met, and at which it is deactivated again if the
threshold is significantly exceeded. This takes place irrespective of whether
persons are present in the detection zone or not.
KNX Application Description for 3000-Series and IR Quattro Micro V3.1
Factory setting Name
Basic illumination
ON-period (for basic
inactive
illumination only: basic
illumination -> active and
basic illumination: basic
illumination ON -> time-
limited)
100 %
Basic illumination is switched OFF after expiry of the ON period that is set
here.
Disable output
0 %
This parameter is used for selecting whether the output can be disabled, and
which telegram is used for disabling and re-enabling the output.
No: the output cannot be disabled.
1
Disabling with ON / enabling with OFF: the output is disabled by a telegram
with value "1" to the disabled object and enabled by a telegram with value
"0".
Disabling with OFF / enabling with ON: the output is disabled by a telegram
with value "0" to the disabled object and enabled by a telegram with value
2
"1".
Behaviour on disabling
No
This parameter is used to select whether to switch the output ON or OFF
before disabling or whether to leave the output unchanged.
No action: no further action takes place before disabling.
ON: output is switched ON before disabling.
500
OFF: output is switched OFF before disabling.
Behaviour on enabling
No
This parameter is used to select whether the output is to resume its activity
after enabling or whether to switch the output ON and OFF first.
Continue control: the output is immediately in normal mode and sets the
output in line with configuration.
100
ON: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
OFF: output is switched ON after enabling. Normal operation is reactivated
after a delay of 5 seconds.
00:05:00

10.4 Constant-lighting control

Name
10
Stay-ON time
constant-lighting control
Stay-ON time is started if no presence is detected. This has the purpose of
preventing the output from switching OFF immediately if the room is vacated
for a short time and having to be switched back ON again when a person
returns to the room.
Stay-ON time can be set from 00:00:10 to 18:12:15.
Automatic starting value
50
Yes: the sensor automatically determines the starting value after artificial light
calibration.
No: the sensor always starts with the given starting value.
Starting value, dimming
level until first Teach
This parameter defines the ON level when constant-lighting control is
started. The value is adopted until artificial light calibration. The sensor then
determines the starting value for directly reaching the light-level setting as
accurately as possible.
Starting value, dimming
level
This parameter defines the ON level when constant-lighting control is started.
- 31 -
Settings Factory setting
hh:mm:ss 00:15:00
Disable
No No
ON for disabling /
OFF for enabling
OFF for disabling /
ON for enabling
no action no action
ON
OFF
Continue control Continue control
ON
OFF
Settings Factory setting
General parameters
hh:mm:ss 00:05:00
Yes Yes
No
1 % ... 100 % 80
1 % ... 100 % 80
