Rotation order of the indexable
inserts
Fitting a new indexable insert
I I N N F F O O R R M M A A T T I I O O N N
Tighten the indexable insert using only the suitable TORX® PLUS-Torque
wrench. Tightening torque:
Tightening the clamping screw
18
18
• Tool diameter < 63 mm: 1 1 , , 1 1 N N m m
• Tool diameter ≥ 63 mm: 3 3 , , 5 5 N N m m
I I N N F F O O R R M M A A T T I I O O N N
The markings on the indexable
insert indicate the rotation order
(1 to 4). This order must be main-
tained!
9. Place the new or rotated indexable in-
sert half the way into the insert pocket.
10. Press the indexable insert into the in-
sert pocket, at the same time sliding
the indexable insert down the insert
pocket.
11. Secure the indexable insert with the
clamping screw.
12. Tighten the clamping screw with the
defined tightening torque in a clock-
wise direction.
R R E E S S U U L L T T
The indexable inserts have been re-
placed and the tool is ready for ser-
vice.
