● Green diode on – indicates voltage on the connector.
●
Red diode on – battery charging in progress.
●
Red diode turns off – battery is fully charged (after 5 hours) or battery temperature is too high (above
45 0 C).
Each time the battery is removed and inserted into a charging station during a recharge, the charging
cycle resets and another 5 hours cycle is started regardless of the current battery capacity.
When the battery temperature rises too much during a recharge (above 45°C) and recharge is
stopped (red diode goes off), remove the battery from charging station, wait approximately for 30
minutes and put the battery back in the charging station. Such temperature rise inside the battery
is not likely and may never occur.
Charging process heats up the batteries. Do not work just after charging is finished - wait until
battery cooles down to ambient temperature, otherwise the battery will be damaged.
SPINDLE BRAKE
Drill driver is equipped with electronic brake, which stops the spindle immediately after the switch button
(6) is released. The brake ensures precision when screwing or drilling and prevents free spindle rotation
after it is switched off.
SWITCHING ON / SWITCHING OFF
Switching on – press the switch button (6).
Switching off – release the switch button (6).
Each time the switch button (6) is pressed, the LED diode (8) lights up to illuminate the workplace.
ROTATIONAL SPEED CONTROL
Screwing or drilling speed can be controlled during operation by increasing or decreasing pressure on the switch
button (6). Speed control enables soft start, which prevents drill slip when drilling in gypsum or glaze, and
helps to control the operation when screwing and unscrewing.
OVERLOAD CLUTCH
Setting the ring (2) in given position causes permanent setting of the clutch to specified torque. When
the set torque is reached, overload clutch releases automatically. It prevents screwing screws too deep or
damaging the drill.
TORQUE CONTROL
● Different screws and materials require different torque to be applied.
●
The bigger the number corresponding to given position, the bigger the torque (
●
Set the ring ( 2) to specified torque.
●
Always start operation with low torque.
●
Increase the torque gradually until appropriate value is set.
●
Use higher settings to unscrew screws.
●
When drilling choose settings marked with the drill symbol. When this setting is set, the torque is the
greatest.
●
Knowledge how to choose appropriate settings comes with practise.
Setting the ring in the drilling position deactivates the overload clutch.
WORKING TOOL INSTALLATION
● Set the direction selector switch (3) in the middle position.
●
Hold the rear ring of the quick release chuck (
appropriately and insert drill or driver bit (fig. E).
●
Hold the rear ring of the quick release chuck (
working tool.

OPERATION / SETTINGS

1) and turn front ring counter-clockwise to open jaws
1), turn front ring clockwise and tighten firmly to install
14
fig. D).
