TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
IP classification:
Protection class:
Power connection:
Power output:
Lamp type:
LED:
Color rendering index (CRI) more than:
Color temperature:
Flash rate:
DMX channels:
DMX input:
DMX output:
Cooling:
Control:
Beam angle (1/2 peak):
Housing color:
Display type:
Dimensions:
Weight:
Accessories
EUROLITE TPC-10 Coupler, silver
EUROLITE Safety Bond A 3x600mm up to 5kg, silver
EUROLITE Safety Bond A 4x1000mm up to 15kg black
EUROLITE DMX cable XLR 3pin 3m black
PSSO DMX cable XLR 3pin 3m black Neutrik
PSSO PowerCon Connection Cable 3x1.5 3m
EUROLITE QuickDMX USB Wireless Transmitter/Receiver
All information is subject to change without prior notice. © 07.12.2021
100-240 V AC, 50/60 Hz
100 W
IP20
Class I
Mains input P-Con (blue), mounting version
Power supply cord with safety plug (provided)
P-Con (gray), mounting version
LED lamp
192 x SMD 5730 0,5 W CW
192 x SMD 5730 0,5 W WW
90 Ra
2700K - 5700K adjustable
1 - 20 Hz
2-1; 2-2; 3-1; 3-2; 4
3-pin XLR (M) mounting version
3-pin XLR (F) mounting version
Temperature-controlled fan
QuickDMX via USB (optional); DMX; Master/slave function;
Stand-alone
120°
Black
LCD
Length: 34,7 cm
Width: 13,8 cm
Height: 21,1 cm
3,50 kg
No. 59006856
No. 58010310
No. 58010344
No. 3022785H
No. 30227810
No. 3023503R
No. 70064704
31/32
00136002, Version 1.1
