GEARBOX - MODULE ASSEMBLY
Gearbox
Item Description
1 Pinion sleeve 7T to 15T
2 O-Ring 22x1.5
3 Plate back dia. 22.0x1.5
4 Gearcase - M28
4 Gearcase - M28
5 Needle 2.5x15.8
6 Needle roller
7 Wheel planet, 19T
7 Wheel planet, 17T
7 Wheel planet, 14T
7 Wheel planet, 16T
7 Wheel planet, 15T
8 Shield
9 Cage, output 2000 rpm
9 Cage, output 3000 rpm
9 Cage, output 5500 rpm
9 Cage, output 550 / 4500 rpm
9 Cage, output 1000 rpm
10 Washer plain
11 Bearing 15x24x5
12 Ring internal
13 Pinion sleeve 9T (without hex)
14 O-Ring 4x1
15 Cage: 1st Stage 1000 rpm
15 Cage: 1st Stage 550 rpm
16 Washer plain 20x12x0.5
17 Pinion sleeve 12T
