MOTOR
A
Grease Molykote G68
B
27652 ISO VG15
7
8
Motor 7T (550, 1000, 3000, 5500 rpm)
Item Description
1 Bearing 4x13x5
2 Pin 2.0 x 8
3 Housing, bearing rear
4 Rotor
5 Blade, rotor radial
6 Cylinder
7 Housing, bearing front
8 Bearing 7x22x7
Motor 12T (4500 rpm)
Item Description
1 Bearing 4x13x5
2 Pin 2.0 x 8
3 Housing, bearing rear
4 Rotor
5 Blade, rotor radial
6 Cylinder
7 Housing, bearing front
8 Bearing 7x22x7
Motor 5T (2000 rpm)
Item Description
1 Bearing 4x13x5
2 Pin 2.0 x 8
3 Housing, bearing rear
4 Rotor
5 Blade, rotor radial
6 Cylinder
7 Housing, bearing front
8 Bearing 7x22x7
07/2015
All manuals and user guides at all-guides.com
6
4
A
5
B
2050500743
Part number
216663
222423
2050503723
2050490983
2050491113
2050503713
2050549363
282123
2050500753
Part number
216663
222423
2050503723
2050497763
2050491113
2050503713
2050549363
282123
2050491473
Part number
216663
222423
2050503723
2050490973
2050491113
2050503713
2050549363
282123
2050504723
Issue no: 16
Series: D
2
1
3
0.040
0.025
A
Qty
1
1
1
1
5
1
1
1
Qty
1
1
1
1
5
1
1
1
Qty
1
1
1
1
5
1
1
1
