Never service damaged battery packs. Service of bat-
u
tery packs should only be performed by the manufacturer
or authorized service providers.
Safety Warnings for Impact Wrenches
Hold the power tool by insulated gripping surfaces,
u
when performing an operation where the fastener
may contact hidden wiring. Fasteners contacting a "live"
wire may make exposed metal parts of the power tool
"live" and could give the operator an electric shock.
Use suitable detectors to determine if there are hid-
u
den supply lines or contact the local utility company
for assistance. Contact with electric cables can cause
fire and electric shock. Damaging gas lines can lead to ex-
plosion. Breaking water pipes causes property damage.
Hold the power tool securely. When tightening and
u
loosening screws be prepared for temporarily high torque
reactions.
Secure the workpiece. A workpiece clamped with
u
clamping devices or in a vice is held more secure than by
hand.
Always wait until the power tool has come to a com-
u
plete stop before placing it down. The application tool
can jam and cause you to lose control of the power tool.
In case of damage and improper use of the battery, va-
u
pours may be emitted. The battery can set alight or ex-
plode. Ensure the area is well ventilated and seek medical
attention should you experience any adverse effects. The
vapours may irritate the respiratory system.
Do not open the battery. There is a risk of short-circuit-
u
ing.
The battery can be damaged by pointed objects such
u
as nails or screwdrivers or by force applied externally.
An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.
Only use the battery with products from the manufac-
u
turer. This is the only way in which you can protect the
battery against dangerous overload.

Technical Data

Cordless Impact Wrench
Article number
Rated voltage
A)
No-load speed
A)
Impact rate
A)
Max. torque
Machine screw diameter
Tool holder
Bosch Power Tools
Product Description and
Specifications
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
The machine is intended for driving in and loosening screws
and bolts as well as for tightening and loosening nuts within
the respective range of dimension.
Product features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1) Tool holder
(2) Locking sleeve
(3) Belt clip
(4) Rechargeable battery
(5) Battery release button
(6) Light
(7) Rotational direction switch
(8) On/off switch
(9) Handle (insulated gripping surface)
(10) Screwdriver bit with ball catch
(11) Universal bit holder
(12) Screwdriver bit
(13) Application tool (e.g. impact socket)
a) Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
GDR 18V-200
3 601 JJ2 1..
V= 18
-1
min 0–3 400
-1
min 0–4 000
Nm 200
mm M6–M16
¼" internal hexagon
Protect the battery against heat, e.g. against
continuous intense sunlight, fire, dirt, water
and moisture. There is a risk of explosion and
short-circuiting.
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
a)
a)
a)
a)
a)
a)
a)
GDX 18V-200
3 601 JJ2 2..
18
0–3 400
0–4 200
200
M6–M16
¼" internal hexagon/
∎ ½"
1 609 92A 6PU | (01.09.2021)
English | 13
GDS 18V-200
3 601 JJ2 3..
18
0–3 400
0–4 200
200
M6–M16
∎ ½"
