Settings and date/time of day
A long press of the clock button "
Set the day of the week at the top of the screen, 1 for Monday, 2 for Tuesday and so on. Press the "
You can change the settings whit the UP/DOWN arrow-buttons. Confirmation is made with the "
Heating mode
The menu button "
" (thermostat in ON mode) allows to select the heating mode between auto and manual. If Auto mode is selected, the
left edge of the screen will show "WEEK" active. The "WEEK" display changes to "STAGE" every few seconds. "STAGE" shows the current
heating period of the day and the preset temperature.
Programming a weekly program for the Auto mode
A set weekly program enables heating of the living rooms according to demand. This is stored in the thermostat and remains even after a
power failure.
The desired day sequence is stored in the main menu under the menu item "PrG" (see table above). A long press (5 seconds) of the menu
button "
" (operating state of the thermostat On) takes you to the programming menu for the Auto mode. Use the up / down arrow keys
to set the first heating phase, hours and minutes. This is confirmed by pressing the menu button again. You will then be prompted to enter the
desired temperature. 6 switching points per day sequence can be set.
Child lock
The child lock is activated and deactivated by pressing the " "and " " keys for 2 seconds.
Scope of delivery: 1x Thermostat with backlight
1x 3m Sensor cable
2x Mounting accessories
1x Instruction manual
The device may only be installed by a qualified electrician in accordance with the wiring diagram.
The existing safety regulations must be observed. To achieve protection class II, appropriate
installation measures must be taken, see VDE0100. This independently mountable device is used
only to control the temperature in exclusively dry rooms with usual environment.
Note:
The application-related device combination of the room thermostat C16 is to be used exclusively
with the external temperature sensor
(sensor) 10kOhm to be used. If the room thermostat is used with another sensor (from a different
manufacturer), any warranty will be voided.
" takes you to the date/time menu.
" button again to enter the hour menu.
" button.
6
