Range of application
The thermostat is used to control water-based underfloor heating systems, electric underfloor heating or other electric heating devices.
Safety instructions and measures
•
Please read these operating manual carefully before using the product for the first time.
•
Use the product strictly as intended, as described in the operating instructions.
•
To avoid electric shock, never immerse the unit in water or other liquids.
•
Make sure that the main voltage in your home matches the operating voltage indicated on the rating plate.
•
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack
of experience and/or knowledge, unless they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
•
Children should be supervised to ensure that they do not play with the appliance.
•
Do not use the appliance if there is obvious damage, for example to the casing or the electrical components or contacts.
Main Menu
All relevant settings for smooth operation are made in the menu. To entert he main menu, press the main button „
thermostat and immediatley after the menu button „
it must be turned Off and ON again. You can switch tot he next menupoint whit the menu button „
changed whit the UP/DOWN buttons. If a change is not desired, the menu button can be used to switch tot he next item.
Display
AdJ
Temperature offset
Mittels eines Offsets lässt sich die tatsächliche Temperatur einstellen.
PrG
The weekly program
5+2 Monday to Friday have the same weekly program, as well as Saturday and Sunday
6+1 Mondy to Saturday have the same weekly program, Sunday has a weekly program on his own.
7 Monday to Sunday have the same weekly progam
LtP
Frost protection function
Eine Frostschutzfunktion hält einen voreingestellten Temperaturwert
Sen
Sensor-settings
The desired area of application is defined here
Internal sensor (IN): is for operation when measurement is to be made only via the room sensor.
External sensor (OUT): is for operation when measurement is to be made only via the floor sensor.
Beide Sensoren (ALL): is for operation with both sensors, the floor sensor has priority.
Top
Temperature range from External sensor
dt0
Hysteresis Internal sensor
Switching hysteresis, is the C° value in which the temperature range may move.
dt1
Hysteresis external sensor
Switching hysteresis, is the C° value in which the temperature range may move. For example, if the desired temperature is
set to 21C° and the hysteresis is set to 3C°, the thermostat would turn on at about 19.5C° and turn off at 22.5C°.
bL
Backlight
The desired illumination time of the display
Sat
State after voltage recovery
Desired state after a power failure
deF
Restore factory settings
USER MANUAL
" for 1 second. You are now in the main menu. If the Thermostat was in the ON state,
Adjustable range
-5 – 5C°
5+2/ 6+1/ 7
ON / OFF
IN – Internal sensor
Out – External sensor
ALL – both sensors
20-60C°
0,5-4C°
0,5-5C°
On – always
Off – on for 5 seconds
Off – Off
On – last state
Page 3-4
" to turn on the
" . The settings can be adjusted or
Factory settings
-2,5C°
5 +2
OFF
Internal-sensor
25C°
1C°
3C°
Off
Off
5
