Setting the Address

Safety

General

Solar Net allows up to 200 Fronius String Control 100/12s to operate simultaneously. The
individual Fronius String Controls are differentiated by the allocation of addresses.
Addresses from 0 - 199 are set using the address switch:
Setting the Ad-
Fronius String Control 100/12
dress - Examples
No. 1
Fronius String Control 100/12
No. 37
Fronius String Control 100/12
No. 123
80
WARNING! An electric shock can be fatal. Danger from DC voltage from solar
modules.
- Make sure that the input and output sides in front of the device are not
charged before connecting anything.
- Any and all connections should only be carried out by qualified electricians.
- Follow the safety rules in these operating instructions.
(1) (2)
0XX
1XX
(1) Jumper for the hundreds' place
(2) Setting dial for the tens' place
(3)
(3) Setting dial for the ones' place
0XX
1XX
0 0 1
0XX
1XX
0 3 7
0XX
1XX
1 2 3
