Installation Position; Fronius String Control 100/12 Installation - Fronius String Control 100/12 MET Bedienungsanleitung

Installation posi-
tion
Fronius String
Control 100/12 In-
stallation
1
3
The Fronius String Control 100/12 can be installed in any position
between the horizontal and vertical.
For vertical and inclined installation position, the cable entries and
0-90°
outlets must always be positioned pointing downwards.
NOTE! The installation of the Fronius DC Box 60/12 shall be done at the appro-
priate mounting brackets only.
Under no circumstances drill holes into the housing!
2
4
61
