JCI1: Chassis Intrusion Connector

This connector allows you to connect the chassis intrusion switch cable.
Using chassis intrusion detector
1. Connect the JCI1 connector to the chassis intrusion switch/ sensor on the
chassis.
2. Close the chassis cover.
3. Go to BIOS > Security > Chassis Intrusion Configuration.
4. Set Chassis Intrusion to Enabled.
5. Press F10 to save and exit and then press the Enter key to select Yes.
6. Once the chassis cover is opened again, a warning message will be displayed on
screen when the computer is turned on.
Resetting the chassis intrusion warning
1. Go to BIOS > Security > Chassis Intrusion Configuration.
2. Set Chassis Intrusion to Reset.
3. Press F10 to save and exit and then press the Enter key to select Yes.

JDMIC1: Digital Microphone Connector

This connector is used to connect to the digital microphone.
H510TI-S01/ H510TI-S09
H510TI-S03/ H510TI-S05
20
Overview of Components
Downloaded from
Normal
(default)
1
1
ManualsNet.com
Trigger the chassis
intrusion event
1 VCC3
3 DMIC_CLK
1 VCC3
3 DMIC_DATA
search engine
2 DMIC_DATA
4 Ground
2 DMIC_CLK
4 Ground
