OPERATING INSTRUCTIONS FOR USE AND PERIODICAL CHECKS
1/ Introduction :
For correct and safe use of this product it is essential to read these instructions carefully. Follow all safety instructions in the respective chapters
of this manual.
This product can be only used if the user instructions has been read and understood these instructions for use, if user(s) undergone training and
if physically and mentally capable of doing so.
In case of doubt, please contact DELTA PLUS GROUP to have the correct support.
This product may only be used as a descender and rescue device for persons.
This product may only be used by one person at a time.
1.1 Visual/functional inspection and maintenance
The visual and functional inspection must be carried out by DELTA PLUS GROUP or a competent person. DELTA PLUS GROUP offers
trainings for that purpose.
This product must be inspected (e.g. damage of the rope etc.) before and after its use.
If the product has been subjected to heavy loads (e.g. due to a fall), it must be sent to DELTA PLUS GROUP for inspection.
If the use of this product does not seem safe anymore (e.g. rope damaged etc.), send it to DELTA PLUS GROUP or a competent person for
inspection and repair. Do not use it! Fill in the inspection protocol carefully.
Each inspection must be entered.
This product must be inspected at least once a year but in any case after max. 2000m distance. Enter the distance in the use protocol.
1.2 Use
The lifetime of metal parts of this product is 20 years. Textile components (e.g. ropes and lanyards) must be replaced after, maximum, 10 years.
This product will heat up during the descent. Touching the housing or holding the long rope end during descent may lead to burns.
If sharp edges (radius< 3mm) cannot be avoided, always use a protecting shield to protect the rope from damage or breaking.
Always fix this product to an anchor device according to EN 795 before descending.
Do not guide the loaded rope end through the eye bolts. This would stop the descent.
This product may only be used in combination with tested and certified products (according to applicable standards for PPE against falls from a
height).
The use protocol must be filled in after each use.

1.3 Storage and transport

Store this product in a dry and clean place protected from mechanical (e.g. sharp edges) and chemical hazards (e.g. acids, gas) at room
temperature and protected from light (e.g. UV).
Store and transport this product in the original packaging.
1.4 Accidents and rescue plan
A suspension trauma can be triggered by falling into the rope, a long descent or if a person is helplessly suspended in the harness for a long time.
Prepare a rescue plan indicating all possible rescue measures in case of emergency before using this product.
Check the use and fall area and make sure to secure, mitigate or remove possible dangers before using this product.

2. Technical characteristic :

2.1 Technical details


Certified according to EN 341:2011 (different from norm kernmantle rope class B)

Steel housing

Aluminium carabiner (EN 362)

Polyamide kernmantle rope (EN 1891 Class A, Teufelberger Patron 9mm)

Descent load min. 20 kg

Descent load max. 150 kg

Descent height max. 300 m

Descent speed approximate 0.8 m/sec

Permissible temperature housing, metal parts -30°C to +150°C

Permissible temperature rope +100 °C

Can be used as a shuttle system
2.2 Marking
All informations about standard, serial number, CE marking and date of production are on the product and at the end of the rope.
3 Use
This product may only be used as a rescue and descender device for persons.
This product may only be used for its intended purposes as defined in these instructions for use and only in combination with tested (certified)
components according to the applicable PPE standards.
Other combinations with uncertified components are not permitted and can be dangerous.
Using this product without having read these instructions for use can lead to accidents resulting in severe injuries or death.
Read these instructions for use carefully before using this product.
In case of doubt or if you have questions please contact DELTA PLUS GROUP .
Inspection
Using this product without having performed a visual and functional inspection can lead to accidents resulting in severe injuries or death.
Always inspect this product before and after its use.
If you are not sure if this product can be used safely, do not use it.
Edge protection
