whether there is good contact at the charging
contacts of the charging unit
If the battery still fails to charge, send
•
the charging unit
•
and the screwdriver
to our customer service center.
Timely recharging of the battery will help it serve
you well for a long time. You must recharge the
battery when you notice that the power of the
cordless screwdriver drops.
6.2 Changeover switch (Fig. 3/Item 10)
The slide switch above the On/Off switch is for
setting the direction of rotation of the cordless
screwdriver and for preventing the cordless
screwdriver from being switched on inadvertently.
You can select between clockwise and counter-
clockwise rotation. Change the direction of rota-
tion only when the equipment is at a standstill.
If you fail to observe this point, the gearing may
become damaged. When the slide switch is in the
middle position, the On/Off switch is blocked.
6.3 On/Off switch (Fig. 3 / Item 9)
Press the On/Off switch to switch the cordless
screwdriver on. Release the On/Off switch again
to switch it off .
6.4 LED lamp (Fig. 3/Item 2)
The LED lamp (2) can be used in poor lighting
conditions to illuminate the area where you want
to screw. To switch ON, press the switch (3) and
to switch OFF press the switch (3) again.
6.5 Angle setting (Fig. 4/Item 7)
The screwdriver can be locked into 2 diff erent
angle settings. To do so, press and hold the lo-
cking button (7) and move the screwdriver into the
desired position. Then release the locking button
(7) again.
Caution! Before you switch on the screwdriver,
make sure that it is correctly locked in the angle
position in question.
6.6 Battery capacity indicator (Fig. 5)
Remove the cordless screwdriver from the char-
ging unit/charging station.
Press the button for the battery capacity indicator
(6). The battery capacity indicator (5) indicates
the charge state of the battery on 3 colored LEDs.
Anl_TC_SD_3_6_Li_SPK1.indb 17 Anl_TC_SD_3_6_Li_SPK1.indb 17
GB
All the LEDs are lit:
The battery is fully charged.
The yellow and red LEDs are lit:
The battery has an adequate remaining charge.
Red LED:
The battery is empty, recharge the battery.
6.7 Changing the bit (Fig. 6)
Warning! Set the changeover switch to its center
position whenever you carry out any work (for
example changing the bit, maintenance , etc.) on
the cordless screwdriver.
Insert the bit (a) into the bit chuck (1).
To remove the bit (a), pull it back out of the bit
chuck (1).
6.8 Screws
It is advisable to use self-centering screws (e.g.
Torx, cross recessed head) as these will enable
you to work safely and reliably. Always make sure
that the bit used is of the same size and shape as
the screw.
7. Cleaning, maintenance and
ordering of spare parts
Danger!
Always pull out the mains power plug before star-
ting any cleaning work.
7.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
7.2 Maintenance
There are no parts inside the equipment which
require additional maintenance.
