IMPORTANT
This guide will help you connect and configure your headset solution. It is important that
you follow the instructions in each section in the order in which they are given.
Please note that the touchscreen base has a built-in setup wizard, which guides you through
all of the required connections and settings, automating many of the tasks. It launches the
first time you apply power to the base.
Basic headset operation is also introduced here. See the full user manual on the supplied
CD-ROM for complete details about how to use your Jabra® GO™ headset.
This product contains font software programs which generate human readable typeface designs ("Font Software")
on base display. The Font Software family is Frutiger® Next licensed to GN Netcom by Linotype®.
JABRA GO 6470
HEADSET DIAGRAM
1 multifunction button (answer/end call, among
other functions)
2 touch panel for volume and mute control
3 Dual noise-blackout microphone
4 Activity and status indicator (multicolor leD)
5 earbud (with speaker)
6 mount for ear-hook wearing-style attachment
7 recharge contact
Figure 1: Jabra GO 6470 headset as seen from the outer
and inner sides, respectively
US
JABRA GO 6470 BASE DIAGRAM
1 Headset cradle
2 touchscreen
3 telephone port
4 Handset port
5 AuX port
6 uSb port
7 power adapter port
8 Security slot and
(recessed) cradle-release button
9 Speaker for ring tones and touchscreen audio
feedback
Figure 2: Jabra GO 6470 base, seen from the front and
back, respectively
