English
Application
Video set Siedle Basic in bus tech-
nology for a 1 or 2-family home.
Encompasses the door station with
integrated camera and 1 or 2 indoor
stations for surface mounting, line
rectifier for max. 10 users, as a
completely coordinated set. Basic
functions calling, speech, vision and
door release.
Electrical voltage
• Mounting, installation and ser-
vicing work on electrical devices may
only be performed by a suitably
qualified electrician.
• Failure to observe this regulation
could result in the risk of serious
damage to health or fatal injury due
to electric shocks.
• Observe DIN EN 60065! In a
building installation, an all-pole
mains switch with a contact opening
of at least 3 mm must be provided.
The transformer must not be
exposed to water drops or sprayed
water! Ensure sufficient ventilation,
paying particular attention to ensure
that ventilation slots are not covered.
• For surface mounting, ensure that
"protection against direct contact"
with active parts is provided. For
details, consult VDE 0100/DIN 57100
part 410.
• When using stranded cores as
cable material, these must be fitted
with wire end ferrules without fail.
Electrostatic charging
As a result of electrostatic charging,
direct contact with the circuit board
can result in destruction of the
device. Direct contact with the circuit
board must therefore be avoided.
14
In the case of video systems, the fol-
lowing mounting situation must be
avoided at all costs:
• direct backlight
• direct sunlight
• very bright image backgrounds
• highly reflective walls opposite the
camera
• lamps or direct light sources
Scope of supply SET CVB 850-1
• CV 850-01
• SNG 850-...
• VIB 150-...
• Siedle screwdriver
• This product information
Scope of supply SET CVB 850-2
• CV 850-02
• SNG 850-...
• 2 x VIB 150-...
• Siedle screwdriver
• This product information
Mounting CV 850-...
1 Unscrew the front of the housing.
To do this, release the Siedle screw
on the underneath of the housing.
Hinge the front of the housing
forward.
2 Surface mounting the door sta­
tion. Recommended mounting
height appr. 1.50 m /4.9 ft. to centre
device. Please note: The cable is
inserted in the lower area of the
base plate!
3 Strip back the installation cable
close to the wall (appr. 10 mm)
and insert the cores into the base
plate. Fasten the base plate using 4
screws. Close the two openings at
the top using rubber stoppers. Install
in accordance with the terminal
diagram.
The cores may only be laid in the
admissible installation space.
4 The pick­up angle of the camera
can be mechanically preadjusted on
the vertical and horizontal by appr.
30° depending on the mounting
situation. To change the pick­up
direction of the camera, it can be
positioned in the required direction.
To change the pick­up direction,
loosen the two cross­head screws
slightly. Position the camera in the
required direction. Then fix the
required position using the two
cross­head screws.
5 Depending on the installation
environment, it may be necessary
to change the door station speech
volume in order to permit clear
speech transmission.
6 Hook the front of the housing
onto the base plate at the top and
close. Tighten the screw on the
underneath of the housing.
Mounting SNG 850-...
7 Mount the line rectifier on the top
hat rail (distribution).
8 Surface mounting is possible with
accessory ZAP 9-0. (not included in
scope of supply)
Mounting VIB 150-...
Strip back cable to appr. 80 mm.
9 Recommended mounting height
appr. 1.60 m to display height/
viewing height.
10 Open the device by pushing in
the locking lever and taking off the
front side.
11 When mounting directly on the
wall, fasten the base plate using
4 screws, paying attention that
the plate is the right way up (top
marking).
12 When mounting on a switch box,
use the screw openings in the centre
of the device, paying attention that
the plate is the right way up (top
marking).
13 Install in accordance with the
wiring diagram. The cores of the
installation cable must be stored
inside the free installation space in
the base plate.
14 With Plug+Play programming
do not close the housing until pro­
gramming is under way. Hook the
housing into the base plate from
above and close by exerting a slight
pressure.
