Installation steps
10
Assemble the front wheels and wheel covers
1
A wheel cover* 2
B M10 lock nut*2
C 12mm washer*4
D wheel lock*2
11
A
A wheel cover* 2
B M10 lock nut*2
C 12mm washers*2
D wheel lock*2
Assemble the gearbox, driving wheel and wheel cover
12
7
C
4
C
B
D
24
9
B 8
D
Connect the
motor after the
C
rear wheels are
installed
24
12
A
13
Installation steps
Install the steering wheel
21
20
M5 lock nut*1
5mm*35mm steering fixing bolt* 1
Install the windshield, rear view
17
mirrors and handrail.
Fix the extreme edge buckles of
the windshield from underbody.
16
18
1
Ø 4mmx12mm
tapping flat head screw* 2
1
6
13-1
13
