Technical Specifications - REVIER MANAGER RM4 eco Benutzerhandbuch

1. TECHNICAL SPECIFICATIONS

MODEL
FREQUENCY
EXTERNAL ANTENNA
RESOLUTION
LENS
MOTION DETECTOR
COVERAGE
IR-FLASH (RANGE)
NIGHT MODE
TRIGGER TIME
MAX. EXPOSURE
AMOUNT OF PICS/
TRIGGER ON SD
TRIGGER INTERVAL (MOTION)/
MANUAL REQUEST
DIMENSIONS
WEIGHT
SD-CARD
POWER SUPPLY
POWER CONSUMPTION (STANDBY)
OPERATING TEMPERATURE
PROTECTION
COLOR
PASSWORD PROTECTION
22
RM4eco (LF-E)
4G (LTE)
3G (UMTS)
2G (GPRS/EDGE)
3dBi
3 / 5 / 8 / 12 / 16 / 20 MP
transmission compressed
58° field of view
Passive Multi-Zone Infrared Sensor (PIR)
15 meter
max. 12 m adjustable in the cam menu
400 Lux
0,6 sec.
1/15 sec.,
in quick mode 1/20 sec.
1-10 recordings adjustable
10 min. /
approx. 3 min. with active premium license*
154 x 112 x 79 mm
474 grams
(w/o batteries)
up to 32 GB
(Micro-SD adapter not recommended)
4, 8 or 12x AA batteries or 6 Volt DC
< 0.3 mA
(< 7 mAh / day)
- 20°C up to + 60°C
IP 66
Camouflage
yes, adjustable
adjustable
*optional
