Dimension Drawing; Wall Mounted - SCANGRIP UNI-EX Anleitung

• The model, specification, dimension and performance of the parts for maintaining should keep the same as the
original ones.
• Check whether the sealing ring is at the original location by achieve the sealing function when close the shell.
• Do not disassemble the sealing parts of the light often. Otherwise the explosive-proof function will be affected.
6. External Dimension and Installation Diagram (Figures)
39 39
70 70

Dimension Drawing

Hook

Wall Mounted
