Logitech PRO X 2 LIGHTSPEED Setup-Anleitung Seite 3

GENERAL HEADSET OPERATION
1
Power switch
– When power on LED will light solid
if battery power >= 10% Light will be
if battery power is <=10% Headset will power down
automatically after 30 minutes of no audio to save
battery life To resume use, turn the power off, then back
on again Timeout value can be adjusted in G HUB
2
Volume wheel
– Rotate up to increase OS volume
– Rotate down to decrease OS volume
3
Microphone mute toggle
– Microphone is active when
Microphone is muted when
4
USB C charging port
– Use provided USB A to USB C charging cable to charge
headset by plugging into USB port on PC
– Cable is for charging and firmware update only –
audio will not play over USB
5
Microphone
– For optimal voice pickup, place foam ball approximately
two fingers' width from the corner of your mouth
– Blue VO!CE functionality can be enabled using G HUB
software
6
Bluetooth / LIGHTSPEED Toggle
– Press to toggle between BT and LIGHTSPEED modes
LED indicator will turn fixed
into Bluetooth mode, or cyan
into LIGHTSPEED mode
green for 5 seconds
red for 5 seconds
red is not visible
red is visible
blue for 5 seconds when put
for 5 seconds when put
5
6
3 ENGLISH
1
2
3
4
