UltraView LCD 17 in./19 in. Monitor
Table 2: Description of VIDEO options
Main menu
Menu options Description
Brightness Adjusts the brightness level for video performance (range 1-100)
Contrast Adjusts the contrast level for video performance (range 1-100)
Tint Adjusts the color tint. (NTSC only) (range 1-100)
Color Adjusts the color density. (range 1-100)
Color Temp. Press (+) or (-) to choose three types of color temperature 9300°K, 6500°K ,
Standard.
Sharpness Adjusts the clarity and focus of the screen image. (range 1-100)
Scan Press (+) or (-) to choose four type of over scan or under scan or full scan or
1 : 1 scan.
OSD H-Pos Adjusts the left or right position of the OSD. (range 1-100)
OSD V-Pos Adjusts the up or down position of the OSD. (range 1-100)
Volume Adjusts the volume control.
PIP/POP Enter PIP-POP submenu.
Language Selects the language of the OSD text: English, Traditional Chinese, Simplified
Chinese, French, German, Spanish, Italian, Portuguese, Russian, and
Japanese.
Recall Press (+) or (-) recall the default value.
Submenu
Menu options
PIP-POP
Sub source
PIP Size
PIP H-Pos
PIP V-Pos
Source Swap
Note: Values can change without notice.
Description
View the video input screen image on the left-top screen.
Select the source of the sub picture: Composite ½ or S-Video
Select the size of the sub picture.
Adjust the left or right position of the sub picture.
Adjust the up or down position of the sub picture.
Swap the picture-in-picture.
17 • EN
