Inhaltszusammenfassung für Rega PLANAR 3 50TH ANNIVERSARY EDITION
-
Seite 2: Safety Precautions
Rega dans le manuel du produit peut entraîner l’annulation de la garantie. En raison des lois locales, les garanties peuvent varier selon le pays dans lequel les unités sont vendues. Veuillez contacter votre revendeur ou Pour obtenir les instructions aux utilisateurs dans votre langue, veuillez visiter distributeur Rega afin de connaître les détails de la garantie. - Seite 3 Enhver uautoriseret ændring eller manglende overholdelse af de af Rega anbefalede retningslinjer i recomendadas por Rega en el manual del producto puede invalidar la garantía. En función de la legislación local, las produktmanualen kan medføre, at garantien bortfalder. På grund af lokale lovgivninger kan garantierne variere alt eft- garantías pueden variar según los países en los que se venden las unidades.
-
Seite 4: Compliance Information
Compliance information Elektro- und Elektronikgeräte Informationen für private Haushalte English Das Elektro- und Elektronikgerätegesetz (ElektroG) enthält eine Vielzahl von Anforderungen an den Umgang mit Elektro- und Elektronikgeräten. Die wichtigsten sind hier zusammengestellt. This symbol indicates that the electronic equipment bearing it should not be disposed of as general household waste at the end of its life. - Seite 5 140 people who design, carefully assemble, and dispatch every single product by hand from our custom-built facility in the Southeast of England. Combine these ideals with a passion for music and you start to see how Rega has successfully made it to this important milestone!
- Seite 6 Unpacking your turntable • Always keep the turntable flat. • Follow the packing guide printed inside the front of the box. • Save the packaging in case you need to transport your turntable in the future. • Place your turntable on a rigid level surface. •...
-
Seite 7: Setup And Connections
Setup and connections Only use the Rega supplied PS1 AC adaptor. Connect the power DIN lead (supplied) between the rear of the Planar 3 50th Anniversary Edition and the DIN socket on the rear of the Neo PSU MK2. Plug the Rega PS1 into the socket labelled ‘24V AC’ and switch the mains power on. - Seite 8 Setting up the RB330 tonearm The Planar 3 50th Anniversary Edition comes fitted with an Exact moving magnet (MM) cartridge. Ensure that the tracking force dial (A) and bias adjustment slider (B) are both set to zero. Place the balance weight (C) on to the balance weight shaft.
-
Seite 9: Adjusting The Speed
Adjusting the speed Note: We recommend the Rega Strobe kit to accurately measure the speed during adjustment (sold separately). Note: The speed is adjusted whilst running at 331/3 rpm and any adjustments made at 331/3 rpm will automatically be applied to 45 rpm. - Seite 10 Rega Strobe and stroboscopic disc (sold separately) The best way to adjust the speed of your turntable is to use the Rega Strobe kit. A stroboscopic disc is an optical instrument used to measure the speed of the turntable by freezing the bars on the disc. The bars are illuminated by an accurate quartz locked LED pulsing at 100Hz.
- Seite 11 A 24V AC plus a 20V DC signal is present on the pins of the plug - if these are shorted it will cause damage to the power unit. Use only with the Rega PS1 power supply or Neo PSU MK2. Never expose the unit to rain or moisture. Do not open the case covers.
- Seite 12 Rega Research UK Rega Research Ltd., 6 Coopers Way, Temple Farm Industrial Estate, Southend-on-Sea, Essex, SS2 5TE...
