WW3, WW6, WW10
1 Introduction
This quick guide will assist you in starting up the unit. Follow
the safety notices or injury to health or property damage may
occur. Carefully read the original operating instructions in-
cluding information on maintenance and troubleshooting
prior to startup. These are located on the included CD and on-
line at
www.buehler-technologies.com
Please direct any questions to:
Bühler Technologies GmbH
Harkortstraße 29
40880 Ratingen
Germany
Tel.: +49 (0) 21 02 / 49 89-0
Fax: +49 (0) 21 02 / 49 89-20
These operating instructions are a part of the equipment. The
manufacturer reserves the right to change performance-, spe-
cification- or technical data without prior notice. Please keep
these instructions for future reference.

1.1 Intended Use

Water alarms are used to monitor hydraulic and lubricating
oils for ingress water and to alert to condensation water. The
devices utilise the natural separation of water and oil to de-
tect any water with a special interface float.
Please note the technical data in the appendix for the specific
intended use, existing material combinations, as well as tem-
perature limits.
WARNING
All device models are solely intended for industrial applica-
tions. They are not safety components. The devices must not
be used if failure or malfunction thereof jeopardises the
safety and health of persons.
Use in explosive areas is prohibited.

1.2 Scope of Delivery

• Water alarm units
• Product documentation
• Connection/mounting accessories (optional)
2 Safety instructions
The equipment must be installed by a professional familiar
with the safety requirements and risks.
Be sure to observe the safety regulations and generally applic-
able rules of technology relevant for the installation site. Pre-
vent malfunctions and avoid personal injuries and property
damage.
4 Bühler Technologies GmbH
The operator of the system must ensure:
• Safety notices and operating instructions are available
and observed,
• The respective national accident prevention regulations
are observed,
• The permissible data and operational conditions are
maintained,
• Safety guards are used and mandatory maintenance is
performed,
• Legal regulations are observed during disposal,
• compliance with national installation regulations.
DANGER
Electrical voltage
Electrocution hazard.
a) Disconnect the device from power supply.
b) Make sure that the equipment cannot be reconnected to
mains unintentionally.
c) The device must be opened by trained staff only.
d) Regard correct mains voltage.
3 Transport and storage
Only transport the product inside the original packaging or a
suitable alternative.
The equipment must be protected from moisture and heat
when not in use. It must be stored in a covered, dry, dust-free
room at room temperature.
4 Setup and connection
DANGER
Electric voltage
Risk of electric shock
a) De-energise the system.
b) The equipment may only be installed, maintained and
put into operation by instructed, competent personnel.
c) Always observe the applicable safety regulations for the
operating site.
4.1 Installation
Be sure to install the water alarm with the red mark at the
same height of the bottom edge of the oil tank (also see draw-
ing below).
WW3 and WW10 have a G1¼ connection for the bottom con-
nection on the tank and a G3/4 connection for the top connec-
tion on the tank. With the WW6, the connections are G3/4 for
the bottom and G1/2 for the top tank connection.
Be sure the attached pipe is tight and ensure a short pipe con-
necting route. Long routes allow more water to collect before
the alarm is triggered.
We recommend installing the water alarm to your tank ac-
cording to the following installation example and using the
corresponding shut-off valve.
