INSTALLATION FIG.1
IMPORTANT: Before installing and wir-
EN
ing the unit, ensure that the main supply
is switched off.
1. Protection grille
2. Fixing screw
3. Connection terminals
4. Outlet with backdraught shutter
5. Cable entry
The DECOR DESIGN can either discharge
directly to the outside or via an individual
or central ducting system (see fig. 2).
The unit can be mounted on the wall or
ceiling using the 4 rubber blocks and the
screws provided.
Drill a hole in chosen position in the wall
or ceiling of: (fig.1)
If the unit is to be installed with individual
ducting, use a standard duct:
- DECOR-100 DESIGN: 100 mm
- DECOR-200 DESIGN: 125 mm
- DECOR-300 DESIGN: 150-160 mm
Loosen the screw (2), which holds the
grille in place (1) and remove the grille.
Ensure that there are no obstructions to
the airflow and that the impeller turns
freely.
Fix the extractor to the wall in such a way
that it is not distorted in order to avoid
noise generation or problems with the
rotation of the impeller. Make sure that
the backdraught shutter opens freely and
has not being damaged in transit.
Introduce the mains cable through one of
the cable point (5) and fix it to the wall so
that the fixing screw (2) is above.
Connect the electrical wiring as set out
16
below and then mount the protection
grille (1) and tighten the screw (2).

ELECTRICAL CONNECTION

This appliance is considered to
be suitable for use in countries
having a warm damp equable
climate as specified in IEC
60721-2-1. It may also be used
in other countries.
The DECOR DESIGN is an extractor de-
signed for a single phase supply, with
voltage and frequency as indicated on
the rating plate of the unit. The units are
manufactured with double electrical in-
sulation (Class II) and therefore they do
not need an earth connection.
In addition to the switch shown in the in-
stallation drawing/diagram, there must
be an All Pole switch in the fixed wiring
with a contact opening of min 3 mm.
The electrical cable must enter the DE-
COR DESIGN through one of the cable
point (5).
Once the cable has been introduced pro-
ceed using the electrical wiring diagram
applicable to the selected model.
DECOR DESIGN C, CZ
These models use the following dia-
grams:
• Fig.3: Fan operating through an inde-
pendent switch.
• Fig.4: Fan operating through the light
switch.
DECOR DESIGN CR, CRZ
This model is provided with an adjustable
