Montage und Inbetriebsetzung
Montage et mise en service
Montagio e messa in funzione
Montaje y puesta en servicio
Installation and initial operation
EU/AUS
USA/CAN
Montage des Arretiergewichtes
Montage du contre-poids
Motagio del contappeso
Montaje del contrapeso
Installation of limits stop weight
All manuals and user guides at all-guides.com
ø35mm /
1 3/8"
S36
Radius min.
= 50mm / 2"
c =
d =
d
Verlängerungsmutter L= 40mm
Ecrou allongé L= 40mm
Dado prolungato L= 40mm
Tuerca de prolongación L= 40mm
Z.503.315
Extension nut L= 40mm / 1 1/2"
c
600 mm, 23 5/8"
300 mm, 11 13/ 16"
3
ø36mm /
1 7/16"
