Introduction
1.
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its
lifecycle could harm the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken
to a specialized company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device
into service. If the device was damaged in transit, don't install or use it and contact your dealer.

General Guidelines

2.
Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.
•
Protect this device from shocks and abuse. Avoid brute force when operating the device.
•
Protect the device against extreme heat and dust.
•
Familiarise yourself with the functions of the device before actually using it.
•
All modifications of the device are forbidden for safety reasons.
•
Only use the device for its intended purpose. Using the device in an unauthorised way will void
the warranty.
• Damage caused by disregard of certain guidelines in this manual is not covered by the
warranty and the dealer will not accept responsibility for any ensuing defects or problems.
• A qualified technician should install and service this device.
• Note that damage caused by user modifications to the device is not covered by the warranty.
• DO NOT use this product to violate privacy laws or perform other illegal activities.
Features
3.
• special and stylish design: suitable for discreet surveillance
• low light sensitivity of 0.05 lux (0 lux when IR on)
• super high resolution
• smart Light Control: dynamically adjusts image performance for clear and accurate images
Operation
4.
Refer to the images on page 2 of this manual.
• Choose a location for the camera, keeping following guidelines in mind
• Do not install the camera in locations where extremely high or low temperatures or
excessive vibrations may occur.
• Avoid mounting the camera near high electro-magnetic fields.
• Do not aim the camera at the sun or other extremely bright objects.
• Do not install behind a glass (or other) window as this will impact image quality.
Note: this camera is designed to be mounted on a dropped ceiling so the signal cables can be
hidden. The recessed part is ±1cm in height; a free space of at least 1,5cm is required
between dropped and original ceiling.
• Apply gentle pressure on the transparent part [1] to remove the plastic cover [2].
• Drill a through hole of 6.2cm diameter.
• Connect the video and power cables [4].
Note: use a 12Vdc regulated power adaptor (not incl.)
• Mount the camera with 3 screws [3] (incl.). Use anchors (incl.) when necessary.
Note: rotate the camera to obtain easy access to the mounting holes.
• Place the plastic cover back on the camera and gently push until it snaps into place.
• Aim the camera towards the desired field of interest.
• Control the focus by gently rotating the lens of the camera.
