Seg SWS 2001 Bedienungsanleitung Seite 10

en
Attention!
The appliance is designed for heating water only.
Attention!
The water level must be below the maximum level and above the minimum. You can choose one of the two ways to
fill the tank with water (see figure 3).
tip!
Use filtered water in the appliance.
Please note that the water fed (regardless of the temperature settings) is not pre-boiled. Therefore, it is recommend-
ed, when preparing baby food, to boil the water and let it cool down to room temperature in advance, and then pour
it into the water tank of the appliance.
Make sure that the plug is inserted into the right socket and that the needed amount of water has been filled. Place a
cup on the removable drip tray, make sure that it is aligned with the dispenser spout, select the needed temperature
and volume and press START/STOP button. Water will continuously flow out of the spout for 5 to 10 seconds, press
the START/STOP button, and the appliance will stop running immediately. If you want to get water again, repeat the
above-described procedure.
3.2. Adjustment of WAter temPerAture And Volume
Fill the tank with water to the maximum level, press and hold the Temp. button for 3 seconds, the temperature display
will show AUT, the flow volume will show 000, press the START/STOP button before locking. The appliance goes into
adjustment mode: sequential adjustments from 45 to 55 to 65 to 75 to 85 to 100 and automatically goes out of it
after completion. It takes about 4 to 5 minutes. Water will flow out of the dispensing nozzle in the process. Place a
large container under the dispensing nozzle.
Attention!
Do not touch the boiling water and steam to avoid scalding.
If the appliance stops running with an audio alarm and the symbol E7 appears on the printed circuit panel, there is
not enough water, and you have to immediately fill the water tank with water.
Since the appliance has the memory feature (for the latest set operating parameters) when inserted into a socket,
wait 60 seconds first.
In case of daily change in the ambient temperature, the water volume will fluctuate between –15% and + 15%
The appliance has a manual thermostat to restore the heating function in case of malfunction, if the unit is out of
order, stops running, does not boil water, you can reset the thermostat using the RESET hole. To do so, press the reset
hole on the rear panel using a special key included into the package, and then turn on and operate the appliance. (see
figure 4).
4. HoW to use tHe disPenser
4.1. WAter feed
Connect the appliance to the power supply. After a beep sound, all the indicators will flash several times. Then, the
control panel will automatically lock, the temperature indicator will show "0", the LOCK button indicator will light up.
2. Place a cup under the dispenser spout.
3. Press and hold the LOCK button to unlock the control panel. The temperature, volume and operation indicators will
flash.
4. Using the Temp. button set the temperature you need as follows: 00°C (room temperature water), 45°C, 55°C,
65°C, 75°C, 85°C, 100°C in a sequential adjustment mode.
5. Use the VOLUME button to set the water volume as follows: 000 (continuous water flow), 100 ml, 200 ml, 300 ml,
400 ml in a sequential adjustment mode.
6. Press the START/STOP button to start feeding water. The temperature and volume indicators will light up on the
control panel.
7. The water feed will stop with the reach of the programmed volume. To stop the water feed, press the START/STOP
button again.
8. If the volume was set to 000 ml, press the START/STOP button again when the required volume is reached.
9. A few seconds after the water feed has stopped, the control panel will lock automatically. To lock the control panel
10
