GB
Indicator LEDs
Note the indicator LEDs on both your remote control and the electronic control unit(s)� The
following instructions can be used as a reference:
LED-Status Meaning
OFF Handset is switched off or is not supplied with power�
RED/GREEN Flashing An attempt is being made to connect to an existing connection�
GREEN Flashing Pairing mode, attempting to establish a new connection�
Signal received, system in operation�
RED Lit, fl ashing, System error: During setup - The remote control was probably set
incorrectly to AWD mode (or the data cable is not connected correctly
illuminated (accom-
if AWD mode was intended) During use - See system error table�
panied by an alarm)
Steady GREEN Switched on and paired with the control unit�
Steady RED Remote control has been completely reset, all modes are set to default
values�
Electronic control unit:
LED-Status Meaning
OFF Off or no power supply�
Lights RED Switched on, power is received, signal connection is expected�
Fast red fl ashing Pairing mode, trying to establish a new pairing�
Slow RED fl ashing Paired with remote control, waiting for commands�
RED Steady, Flashing, Stea- See system error table�
dy (accompanied by alarm
from remote)
System errors
System errors can occur for various reasons� Contact Berger Customer Service if errors persist�
Use the table below for reference and troubleshooting�
For each LED display, the errors are indicated in the following way:
Constant on Flashing up to 8 times
44
Constant on
All system errors are accompanied by an alarm from the remote control, which goes off to-
gether with the fl ashing after about 8 seconds or until the error is corrected� Various errors are
listed below:
(RED) LED Status Description
Overcurrent (motor)
Overcurrent (battery)
2 Flashing
3 Flashing Undervoltage
4 Flashing Overvoltage
5 Flashing Overtemperature
6 Flashing Critical
Undervoltage cut-off
M2 Motor driver failure
8 Flashing sign
M3 Motor driver failure
GB
Possible cause and measure
Usually caused by overloading the system,
avoid excessive load or steep slopes,
check that the vehicle brakes are not
applied�
Usually caused by a weak/discharged
battery, check the voltage�
Usually caused by an incompatible battery
or when a charging system is present
during operation�
Usually caused by prolonged operation
with a high load�
- Wait 5 minutes until the electronics have
cooled down�
- Divide long trips into shorter „trips"�
Usually caused by a loose or dry connec-
tion in the wiring or the use of a dead
battery�
- Make sure the system is switched off
and check the wiring and condition of
the terminals�
- Check the condition of the battery by
appropriate means (do not rely on the
caravan's internal battery monitor)�
Triggered if no output voltage is detected:
- Possible short circuit on the motor�
- Possible failure of the control system�
Switch the unit off and on again� If the
problem persists, stop using it and con-
tact service@fritz-berger�de�
