The charger has 2 LED indicators (12) which indi-
cate the status of the charging process:
Red LED Status Green LED status
Off Off
Off On
On Off
Inserting the Cartridge
• Pull the rack (3) backwards using the rack handle
(7).
• Cut open the front side of the cartridge and screw
on a dispensing nozzle.
• Insert the cartridge into the cartridge holder (1).
• Slide the unlocked rack (3) forwards until the
plunger (2) comes into contact with the cartridge.
• If necessary, cut the dispensing nozzle to size, so
that it ideally meets your requirements.
4. OPERATION
Adjusting the Feed Rate
• You may adjust the feed rate of the rack (3) by
pressing the (+) or (-) buttons (5/6) while simul-
taneously pressing the trigger switch (8).
• Four different speeds can be selected, the
selected speed is shown by the indicator lights
(4). Note that the amount of material squeezed
out depends on two factors: The size of the
opening in the dispensing nozzle and the se-
lected feed rate.
Switching On and Off
• To switch on the caulking gun, press the trigger
switch (8). The rack (3) will start moving for-
wards.
• To switch off the caulking gun, release the
trigger switch (8). The rack (3) will move back-
wards slightly into a parking position to stop
unwanted dripping.
Working Advice
• Comply with the manufacturer's instructions
regarding the material to be applied. Certain
WWW.VONROC.COM
materials can only be used within a certain
temperature range or can only be applied to
specifi c surfaces.
Charger status
• Open and use the cartridges in accordance with
No power
the manufacturer's specifi cations.
• Only trim the dispensing nozzle if the material is
Standby mode:
securely within the cartridge holder.
- No battery is
• Adjust the feed rate to ensure a smooth and
inserted or,
consistent application of material in one appli-
- Battery inserted
cation.
but charging has
• Ensure that the surface onto which the material
fi nished
is to be applied is clean, dry and free from
Battery charging in
grease.
progress
5. MAINTENANCE
Maintenance and Cleaning
• To ensure safe and effi cient operation, always
keep the power tool and the ventilation slots
clean.
• Clean the dispensing nozzles, the cartridge
holder and the rack with he press thoroughly
after each use in accordance with the speci-
fi cations provided by the manufacturer of the
consumable. The battery and the handle can be
cleaned using a damp cloth.
• The caulking gun is maintenance-free and does
not contain any parts that need to be replaced
or maintained.
ENVIRONMENT
Only for EC countries
Do not dispose of power tools into domestic waste.
According to the European Guideline 2012/19/EC
for Waste Electrical and Electronic Equipment and its
implementation into national right, power tools that
are no longer usable must be collected separately
and disposed of in an environmentally friendly way.
Remove the battery from the power tool
before carrying out work on the power tool
(e.g. maintenance, changing tool, etc.). The
battery should also be re-moved for
transport and storage. There is risk of injury
from unintentionally pressing the on/off
switch.
Faulty and/or discarded electrical or
electronic apparatus have to be collected at
the appropriate recycling locations.
