Connection Diagram

Before using the camera, please connect your camera as instructed
below to finish initial setup.
1. Connect the camera to a Reolink NVR (not included) with an Ethernet
cable.
2. Connect the NVR to your router, and then power on the NVR.
NOTE: The camera should be powered with a 12V DC adapter or a PoE
powering device such as PoE injector, PoE switch or Reolink NVR
(not included in the package).
Power Adapter
OFF ON
AUDIO
DC 48V OUT USB HDMI
* You may also connect the camera to a PoE switch or PoE injector.
5 English
PoE IP Camera
Reolink NVR Router
1 3 5 7
eSATA
VGA LAN 2 4 6 8
Ethernet Cable
Ethernet Cable

Set up the Camera

Download and Launch the Reolink App or Client software, and follow the
onscreen instructions to finish initial setup.
• On Smartphone
Scan to download the Reolink App.
• On PC
Download path of the Reolink Client: Go to https://reolink.com
> App & Client.
NOTE: If you are connecting the camera to a Reolink PoE NVR,
please set up the camera via the NVR interface.
2
> Support
English 6
