u To remove the drawers at a
door angle of 90°:
u As you pull out the
drawers, push slightly to
the side then pull them up
and out.
u The bowl in the well is suitable for storing small parts
that are not used very often.

5.9 Shelves

5.9.1 Repositioning the shelves
u Taking out the tray: lift
the tray at the front and
pull out.
u Reinserting the tray:
simply slide it in as far as
it will go.
5.9.2 Disassembling the shelf
u The shelves can be disas‐
sembled for cleaning.
* Depending on model and options

5.10 FlexArea

You can remove the shelves
as well as the trays. In this
way you can create space
for large food items, such
as poultry and meat. Large
portions of game as well
as tall bakery items can be
frozen whole and then further
prepared.
u Each drawer can hold max. 25 kg of frozen food.
u The trays can each hold a max. of 35 kg of frozen food.

5.11 Information system

(1) Bread
(2) Ice cream
(3) Fish

5.12 Freezer pack

Fig. 3
Freezer packs prevent the temperature rising too quickly
should there be a power cut.
5.12.1 Using freezer packs
u Put the fully frozen freezer
packs on the frozen food in the
top front section of the freezer
compartment.

6 Maintenance

6.1 Defrosting with NoFrost

The NoFrost system automatically defrosts the appliance.
The moisture condenses on the evaporator, is periodically
defrosted and evaporates.
u The appliance does not have to be manually defrosted.

6.2 Cleaning the appliance

Clean the appliance regularly.
WARNING
Risk of injury and damage as a result of hot steam!
Hot steam can lead to burns and can damage the surfaces.
u Do not use any steam cleaners!
Maintenance
Fig. 4
(4) Vegetables
(5) Meat
(6) Fruit
39
