Technical data:
Type
Transmitter
Wavelength (TX 1270)
Wavelength (TX 1330)
Bandwidth@–20dB
Optical Output Power
Extinction Ratio (ER)
SMSR
Receiver
Wavelength (RX 1270)
Wavelength (RX 1330)
Sensitivity
Overload Input
LOSA
LOSD
Hysteresis
Data transmission
Bit rate
BER
Applications
Compliances
General
Operating voltage
Operating temperature range
Storage temperature range
Operating humidity (non-condensing)
Comments
EU Declaration of Conformity
Hereby AXING AG declares that the CE marked products comply with the
valid EU guidelines.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Technical improvements, changes in design, printing and other errors reserved.
Page 1 of 2 | AXING-BA_SFPB.pdf | 2022-08-29
SFPB 10-1023
SFPB 10-1032
1260 ... 1280 nm
-
-
1320 ... 1340 nm
–8.2 ... 0.5 dBm
–8.2 ... 0.5 dBm
-
1260 ... 1280 nm
1320 ... 1340 nm
-
–14.4 dBm*
–14.4 dBm*
0.5 ... 5 dB**
10GBASE-LR/LW
10G Ethernet
OBSAI (3.072 Gb/s, 6.144 Gb/s)
CPRI (2.4576 Gb/s, 4.9152 Gb/s, 6.144 Gb/s, 9.8304 Gb/s)
IEEE 802.3ae
SFF-8431 Rev 4
SFF-8472 Rev 10
3.14 ... 3.46 V
–40 ... +85 °C
* Measured with a PRBS 2E31–1 test pattern, @10.3 Gb/s, EX = 5 dB, BER < 10E–12.
** The LOS Hysteresis to minimize "chatter" on the output line. In principle, hysteresis alone does not guarantee chatter-free
Manufacturer
AXING AG
Gewerbehaus Moskau
8262 Ramsen
SFPB 10-2023
SFPB 10-2032
1260 ... 1280 nm
-
-
1320 ... 1340 nm
≤ 1 nm
–2 ... 3 dBm
–2 ... 3 dBm
≥ 3.5 dB
≥ 30 dB
-
1260 ... 1280 nm
1320 ... 1340 nm
-
–15 dBm*
–15 dBm*
≥ 1 dBm
≥ –38 dBm
≤ –30 dBm
10.3 Gb/s
< 10E–12
0 ... 70 °C
5 ... 95 %
operation.
EEA contact address
Bechler GmbH
Am Rebberg 44
78239 Rielasingen
SFPB 10-1023 | SFPB 10-1032
SFPB 10-2023 | SFPB 10-2032
premium-line
Bidirectional SFP+ Transceivers
Operation instructions
