Connections, Cable Reel and On-Off Switch

8
Fig. 3: Connections, cable reel and on-off switch
Pos . Designation
1 ETHERNET
2 REMOTE
3 USB
4 On-Off switch
5 Potential equalization
6 Strain relief for the power supply
cable
7 Power supply
8 Cable reel
18 Operating Instructions Flexsafe
1 2
8
Description
Connection for Sartorius Service personnel only. Is sealed with a
cover cap.
Connection for remote control. Is sealed with a cover cap.
Connection for USB mass storage. Is sealed with a cover cap.
Switches the device on or off.
Connection for potential equalization cable
Connection for power supply cable
Used for securing longer connection cables.
Pro Mixer Drive Unit
®
