2. Connection & Access to the Server

2.1 Connecting the server

LNB 2
1. Connect the SAT>IP server to your Internet router. Use a suitable LAN cable.
2. Connect the coaxial cables from the LNB or multiswitch to the corresponding
connections (see table).
3. If you have connected all cables, you can plug in the power supply.
Connection with a Single LNB, Twin LNB or Multiswitch
Single LNB
Twin LNB
Multiswitch (1st line)
Multiswitch (2nd line)
Connection with a Unicable LNB or Unicable system
Unicable LNB / Unicable System
Connection with a JESS LNB or JESS system
JESS LNB / JESS System
Note:
If you are using Unicable or JESS, you must make further settings in the „System
settings" menu item.
LNB 1 LAN
ENGLISH
USB Reset button
Factory setting
LNB 1
LNB 1 / LNB 2
LNB 1
LNB 2
LNB 1 / LNB 2 (with Splitter)
LNB 1 / LNB 2 (with Splitter)
Power supply
