Technical Data - RUSTA 901513020101 Gebrauchsanweisung

MAINTENANCE
• Change the dust bag: when the wind indicator turns to be red, it is time to clear
the dust or replace with a new bag. (Fig1)
1. Open the front cover by clicking down the clip. (Fig2)
2. Take out the bag then remove the full dust bag. (Fig3)
• Exchange the outlet filter: Press and click down the clip to remove the outlet
cover to change the filter. (Fig4,5)
• The motor protection filter should be cleaned or changed when it´s dirty. (Fig6,7)
Fig. 1
Fig. 4

TECHNICAL DATA

Voltage
Output
Protection class
Bag capacity
Filtering
Cord length
Total range
Metal telescopic tube
Sound level
Dimensions
Weight
Fig. 2
Fig. 5
220–240V~50/60Hz
800W
3,5 l
HEPA-filter
7 m
9,5 m
58–90 cm
max 69 dB
500 x 330 x 325 mm
5,9 kg
Fig. 3
Fig. 6 Fig. 7
5
