14 Time adjustment

To adjust the date an time:
• Press the START/STOP button to activate the display.
• Press the MODE button, the month will blink on the display.
• Press the UP or DOWN button to change the month.
• Press the MODE button to confirm the month. The day will
blink on the display.
• Change the day, hours and minutes as described above,
using the UP or DOWN button to change and the MODE
button to confirm every setting.
After setting the minutes, the device is ready to use.

15 Technical specifications

Power source
Measurement method
Measurement zone
Accuracy
Pressure sensor
Inflation
Deflation
Memory capacity
Auto-shut-off
Operation environment
Storage environment
Weight
Wrist circumference
Limited patient
Dimensions
K.B.
Classification
*Specifications are subject to change without notice.
9
3V DC: Two LR03 (AAA) Non rechargeable batteries
Oscillometric
Pressure: 0 ~ 300 mmHg
Pulse: 40 ~ 199 beats/minute
Pressure: ± 3 mmHg
Pulse: within ± 5% of reading
Semi-conductor
Pump driven
Automatic Pressure release valve
3 Memory zones for each 30 memories
1 minute after last key operation
+10°C ~ + 40°C - < 85% RH
-20°C ~ + 70°C - < 85% RH
120g (without batteries)
135 ~ 195 mm
Over 18 years old
74(L) x 84(W) x 32(H) mm
Short time operation 2 minutes
• Internally powered equipment
• Classification of type BF (applied part)
• IPX0
• Not suitable for use in presence of flammable
anaesthetic mixture with air or with oxygen or
nitrous oxide
• Continuous operation with short-time loading
TOPCOM BPM Wrist 5331
