EN
Adjusting the direction of rotation (Fig. D)
• Set the direction switch (4) to position "
order to drive screws or to use it for drilling.
• Set the direction switch (4) to position "
order to remove screws.
Switching the machine on and off (Fig. D)
The on/off switch (5) is used for activating the
machine and adjusting rotation speed.
• Pressing the on/off switch (5) will activate
the machine, the further the switch is being
pushed, the faster the drill will turn.
• Releasing the on/off switch (5) will stop the
machine.
• Move the direction reversing switch (4) to the
middle position to lock the movement of the on/
off switch.
Adjusting the torque (Fig. D)
The machine has 10 different torque settings
and a special drill mode to set the power being
transmitted to the chuck. By rotating the torque
adjustment ring (3), screws can be driven to
a predetermined depth, which is ideal for repetitive
work. The higher the number, the more torque will
be transmitted.
• Select a low setting for small screws or soft
work material.
• Select a high setting for large screws, hard
work materials and when removing screws.
• You should preferably choose a setting as low
as possible when driving screws. Select a high-
er setting if the motor slips before the screw is
fully tightened.
• For drilling, turn the torque adjustment ring (3)
to the setting for drilling (
counterclockwise.
Ensure that the direction switch (4) is
always set to "
The machine is equipped with electronic
overload protection function. When the
machine gets overloaded it will shut down
automatically. When this happens, please
wait for a few seconds to let the overload
protection reset itself.
8
" in
" in
) by fully turning it
" during drilling.
4. MAINTENANCE
Before cleaning and maintenance, always
switch off the machine.
Clean the machine casings regularly with a soft
cloth, preferably after each use. Make sure that
the ventilation openings are free of dust and dirt.
Remove very persistent dirt using a soft cloth mois-
tened with soapsuds. Do not use any solvents such
as gasoline, alcohol, ammonia, etc. Chemicals such
as these will damage the synthetic components.
ENVIRONMENT
Faulty and/or discarded electrical or
electronic apparatus have to be collected at
the appropriate recycling locations.
Only for EC countries
Do not dispose of power tools into domestic waste.
According to the European Guideline 2012/19/
EC for Waste Electrical and Electronic Equipment
and its implementation into national right, power
tools that are no longer usable must be collected
separately and disposed of in an environmentally
friendly way.
WARRANTY
VONROC products are developed to the highest
quality standards and are guaranteed free of
defects in both materials and workmanship for the
period lawfully stipulated starting from the date of
original purchase. Should the product develop any
failure during this period due to defective material
and/or workmanship then contact VONROC directly.
The following circumstances are excluded from this
guarantee:
• Repairs and or alterations have been made
or attempted to the machine by unauthorized
service centers;
• Normal wear and tear;
• The tool has been abused, misused or
improperly maintained;
• Non-original spare parts have been used.
This constitutes the sole warranty made by compa-
ny either expressed or implied. There are no other
