ETS 3000 IO-Link
22 Accessories
22.1 Electrical connection
ZBE 06 (4 pole)
Mating connector M12x1,
right-angled
Cable diameter:
3.3 .. 6.6 mm
(0.13 .. 0.26 inch)
Part No.: 6006788
ZBE 06-02 (4 pole)
Mating connector M12x1,
right-angle with 2 m
(78.7 inch) cable,
Part No.: 6006790
ZBE 06-05 (4 pole)
Mating connector M12x1,
right-angle with 5 m (197
inch) cable,
Part No.: 6006789
Colour code: Pin 1:
Pin 2:
Pin 3:
Pin 4:
Status: 2022-07-13
brown
white
blue
black
HYDAC ELECTRONIC GMBH
27
Part No.: 669904 E
