6. INTRODUCTION
The GE 20-2 is a next-generation high-efficiency portable electric inflator, which stands for reliability
and functionality. The GE 20-2 is equipped with a double-piston pumping unit that allows any object
to be inflated to a pressure between 10 and 1,500 mbar. The inflator starts when the ON button is
pressed and automatically stops when the set pressure in the pressure gauge is reached. The device
stops when the user presses the OFF button.
The GE 20-2 is fully portable as the battery is integrated in the device. When the battery is low (red light
on the pressure gauge), the inflator can be connected to a cigarette lighter socket or to an external
12V battery via the power clamps. The battery can also be charged by a 12V cigarette lighter socket
or 110-240 AC/DC adapters.
The inlet port is protected by a multilayer filter, the outlet port is equipped with a check valve.
The unit is protected against overheating. In the event of high outside temperature or overuse, the
inflator will automatically stop and a red LED on the pressure gauge will indicate its status. The device
can be restarted when the red LED goes OFF.
7.RECOMMENDED USES
Inflatable items, such as: SUPs / Small rubber dinghies (3/4 m) / Kayak / Kites / Rafts / Air
mattresses / Swimming pool floats / etc.

8. TECHNICAL SPECIFICATIONS

SAFETY FUSE
MAX. PRESSURE
FLOW RATE
ITEM FUNCTIONS
(mbar)
(L / minute)
GE 20-2
125
30 A 1,500 (22 PSI)
INFLATION
PRESSURE SETTINGS: PRESSURE GAUGE WITH AUTOMATIC SWITCHING OFF
INFLATION FITTINGS: AVAILABLE FOR MOST COMMON VALVES
CARRY BAG DIMENSIONS: 220x320x220 mm
9. USE FOR INFLATING
ACCESSORIES AND POWER CABLES
1. All accessories are located inside carry bag upper compartment: inflation hose, power cables, and
battery charger.
CONNECTING THE ACCESSORIES
1. The inflator is supplied with standard conical adapters that are located inside carry bag upper compartment.
2. Make sure that the OFF button has been pressed.
3. Take the hose from the carry bag.
4. Connect the air hose to the port to inflate (OUT).
5. Assemble the most suitable adapter for the inflator.
TURNING ON THE INFLATOR
1. To INFLATE, connect the hose to the outlet port (N3 fig. on p.3).
2. Set the desired pressure on the pressure switch (N2 fig. on p.3).
The inflator will automatically stop when the set pressure is reached.
3. The device starts when the ON button is pressed. Depending on the battery level, the pressure gauge
LED will show three different colours:
GREEN: charged battery.
YELLOW: battery running low.
RED: battery low.
When the LED is not GREEN, we recommend you to recharge before operating. Otherwise, the inflator
can be used by connecting it to a car cigarette lighter socket (N8 on p.3) or to an external battery via a
cable with power clamps (N7 on p.3).
NOTE The inflator battery will not be charged when using the cigarette lighter cable or the power terminal cable.
