3. Usage
AQA therm HFB-1717 BA
Media
Pre-pressure
Back pressure
Fluid category of the
system separator BA
AQA therm HES
Media
Pre-pressure
4. Technische Daten
AQA therm HFB-1717 BA
Installation position
Operating temperature
Pressure regulator con-
nection ball valve system
separator
Dranage connection
Connector size
AQA therm HES
Installation position
Operating temperature
Connectore size
3329_EBA_AQA therm HFB/HES NEU.indd 11
Water
Max. 10 bar
Adjustable from 1.5 - 4 bar
present to 1.5 bar
4 (poisnouns, very poiso-
nous, carcinogenic, radio-
active substances)
Water
Max. 4 bar
Horizontal with a
downstream drainage
connection
Max. 65 °C
G 1/4"
HT 50
1/2" external thread
Horizontal with down-
stream cartridges, cart-
ridges optionally available
Max. 30° C of filling
water; max. 50° C device
temperature for the shut-off
ball valve (closed) through
the transfer of heat to the
heating installation; max.
40° C ambient temperature
1/2"
Connector size R
Dimensions H
h1
h2
h3
L
l1
l2
Kvs value m /h
3
Installation height min. 550 mm from the ground to
the middle of the pipe in order to safely ensure a
cartridge exchange.

5. Scope of delivery

The AQA therm HFB-1717 BA consists of:
- integrated shut-off ball valves, on the inlet and
outlet side (1)
- system separator type BA with drainage
connection (8), cartridge insert, integrated dirt
trap on the inlet side, backflow inhibitor on
the outlet side and three measuring points with
sealing plugs
- pressure regulator with manometer
- insulation
The AQA therm HES consists of:
- a water meter on the inlet side (5)
- a mixing device (7) and possible connection of
either the AQA therm HRC or SRC (4)
- vent valve or extraction valve (6)
- shut-off ball valve on the outlet side (9)
- insulation
- blanking plug
GB
1/2"
526 mm
74 mm
452 mm
162 mm
495 mm
137.5 mm
138 mm
0.45
11
