Storage tempe-
rature
Recommended
battery
Weight (Without
0.38 kg 0.42 kg
Batteries)
119x75x 119x90x
Dimensions
123 mm 123 mm
* The working range may be reduced by unfavourable
environmental conditions (e.g. direct sunlight).
Model No.
Battery Type
Voltage
Capacity
Recommended charger
Weight
Model No.
Charger input
Charger output
Charging time
Recommended batterie
Weigh
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-6.
1. On/off button: horizontal laser line
2. On/off button: vertical laser line (or lines*)
3. Lock switch
4. Laser beam outlet
5. Battery cover
6. Operating mode LED
7. Magnetic bracket
8. Hanging hole
9. Adjusting knob (for height)
10. Mounting wheel
11. Remote control
12. Charger
13. Charger LED indicator
14. USB-C plug
15. Battery
16. USB-C charging socket battery
WWW.VONROC.COM
5~30 °C
LL802AA
0.38 kg 0.42 kg
119x75x 119x90x
123 mm 123 mm
LL802AA
Lithium-Ion
3.7V
5000 mAh
LL803AA
0.09 kg
LL803AA
100-240V,50/60Hz
5V 1.7A
5000mAh battery 5 hours
LL802AA
0.07 kg
17. 1/4" tripod connection
18. 5/8" tripod connection
19. 1/4" male threat
20. Magnets
21. Laser target plate
*LL505DC and LL506DC only
3. ASSEMBLY
Before any work on the device, remove the
battery.
The battery must be charged before first use.
Inserting / replacing the battery (Fig. C)
Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.
1. Open the battery compartment cover (5).
2. If applicable, remove the other battery (15).
2. lnsert battery (15).
3. Close the battery compartment cover (5).
Removing the battery from the device (Fig. C)
1. Open the battery compartment cover (5).
2. Remove the battery (15).
3. Close the battery compartment cover (5).
Charging the battery (Fig. B)
1. Take the battery (15) from the device.
2. Insert the USB-C plug (14) of the charger into
the USB-C charging socket (16) as shown in
figure D.
3. Plug the charger plug into an electrical outlet
and wait for a while. The LED indicator (13) on
the charger will lighten up and show the char-
ger status.
LED indicator (Fig. A)
The charger (12) has 1 LED indicator (13) which
indicates the status of the charging process:
LED Charger status
Red Battery charging in progress
Charging finished, battery fully
Green
charged
