VONROC LL503DC Bersetzung Der Originalbetriebsanleitung Seite 12

EN
the device starts to beep, the permissible incli-
nation range of 4 degrees is exceeded. Position
the device horizontally.
3. After it self-levels, make a horizontal mark on
the wall anywhere along the horizontal line to
indicate the height of the beam. Label this as
point A as shown in Fig. H1.
4. Turn the device 180°, and after it self-levels,
mark point B as shown in Fig. H2.
5. Turn the device 180°. Position the device as
near as possible to the wall at the height of
point A as shown in Fig. H3.
6. Turn the device 180°, and after it self-levels,
mark point C. This mark should either be direct-
ly above, below or on top of point B as shown in
Fig. H4. The difference between points B and C
is the tolerance.
When B and C are more than 0.8 mm / m apart, an
adjustment is necessary. Contact your authorized
dealer or else the Vonroc Service Department.
Cleaning
NOTICE! Risk of product damage! Never
submerge device in water while cleaning.
Do not use cleaning agents or solvents. Wipe the
device using a dry cloth.
Storage
NOTICE! Risk of product damage! Always
handle measuring instruments with care.
• Store the product in a dry, well-ventilated place.
• Only store and transport the measuring tool in
the protective bag.
• Prevent large temperature fluctuations: Always
temper the product for a while before use in
extremely cold or hot environments.
ENVIRONMENT
Faulty and/or discarded electrical or
electronic apparatus have to be collected at
the appropriate recycling locations.
Only for EC countries
Do not dispose of power tools into domestic waste.
According to the European Guideline 2012/19/
EC for Waste Electrical and Electronic Equipment
and its implementation into national right, power
12
tools that are no longer usable must be collected
separately and disposed of in an environmentally
friendly way.
WARRANTY
VONROC products are developed to the highest
quality standards and are guaranteed free of defects
in both materials and workmanship for the period
lawfully stipulated starting from the date of original
purchase. Should the product develop any failure
during this period due to defective material and/or
workmanship then contact VONROC directly.
The following circumstances are excluded from this
guarantee:
• Repairs and or alterations have been made
or attempted to the machine by unauthorized
service centers;
• Normal wear and tear;
• The tool has been abused, misused or
improperly maintained;
• Non-original spare parts have been used.
This constitutes the sole warranty made by compa-
ny either expressed or implied. There are no other
warranties expressed or implied which extend
beyond the face hereof, herein, including the im-
plied warranties of merchantability and fitness for
a particular purpose. In no event shall VONROC be
liable for any incidental or consequential damages.
The dealers remedies shall be limited to repair or
replacement of nonconforming units or parts.
The product and the user manual are subject to
change. Specifications can be changed without
further notice.
