3.2 Normal states
1. Hold "Set" for 2 seconds to enter into time setting
2. Click "Alarm" to switch the alarm on/off
3. Hold "Alarm" for 2 seconds to enter into Alarm setting
4. Click "Up" to switch between 12 hr/24 hr
5. Press "Down" to switch between °C/°F
6. When ALARM rings, click "snooze" to enter into the snooze state every 5 minutes
7. Press "Channel" to switch RF channel, CH1 → CH2 → CH3
8. Hold "Channel" key for 2 seconds to clear out all data of current "Channel"
3.3 Time set
1. Hold "Set" key for 2 seconds to enter into time setting
2. The sequence of time setting: Year (2000-2050) → Month → Date → Language → Hour →
Minute → Time zone → Exit
3. There will have 1 Hz fl ashing during setting
4. Press "Set" to confi rm the setting, and enter the next setting state
5. Press "Up" one time, the setting will go ahead for one step; hold the key for 2 seconds, it will
run forward by 8 steps/second.
6. Press "Down" one time, the setting will backward for one step; hold for 2 seconds, it will run
back by 8 steps/second.
7. Moon phase is changed accordingly
8. The system will exit automatically if no key is operated in 8 seconds.
3.4 Alarm set
1. Hold "Alarm" key for 2 second to enter into alarm setting
2. The sequence of alarm setting: Hour → Minute → exit
3. There will have 1 Hz fl ashing during setting
4. Press "Alarm" to confi rm the setting, and enter the next setting state
5. Press "Up" one time, the setting will go ahead for one step; hold the keys for 2 seconds, it will
run forward by 8 steps/seconds.
6. Press "Down" one time, the setting will backward for one step; hold for 2 seconds, it will run
back by 8 steps/second.
7. The system will exit automatically if no key is operated in 8 seconds.
Function and effect
4.1 The receiving function of RF
1. After installing the battery and checking temperature/humidity, it will enter RF receiving state
automatically for 3 minutes.
2. Under normal display mode, hold the "Channel" key for 2 seconds to clear out the channel
information
3. If there is no effective signal with same ID code received for the current channel in 35 minutes,
the temperature of that CH will show "--. -".
4. The temperature display will resume back when the correct signal is received again
4.2 The function of alarm
1. The BUZZER will ring for 2 seconds as below:
a. 0 – 10 sec.: one "beep" per second
b. 10 – 20 sec.: two "beeps" per second
c. 20 – 30 sec.: four "beeps" per second
d. After 30 sec.: "beeps" continuously
2. When the alarm goes off, click "Snooze" key once to enter states 5 minutes snooze states,
exit if any other key is clicked.
