Installing and wiring the thermostat

To mount the thermostat to the wall box/wall socket, first open the
thermostat by gently pushing the tabs in the buttom of the thermo-
stat. To fix the thermostat, screw in properly sized screws into the
wall socket/wall box.
When proberly fastend and cables connected (see diagram below),
mount the frontpanel to the backpart again.
Wiring diagram
Electrical wall
box/socket
85-240V~
Max
13A
EN
Remote sensor
5
