Filamenten zu vereinfachen und zu perfektionieren� Es bietet ein hervorragendes Herstellungser- lebnis ohne vorherige Programmier- oder 3D-Druckerfahrung� Zum Drucken eines 3D-Objektes benötigen Sie den SIMPLEX 3D-Filament-Drucker, die SIMPLEX sliceware und ein SIMPLEX Filament Ihrer Wahl� „App Store“, „Apple“, „Google“, „Play Store“, „Android“ sind eingetragene Warenzeichen der Firmen Apple oder Google�...
Der SIMPLEX 3D-Filament-Drucker stellt dreidimensionale Objekte aus geschmolzenem Filament in nur einem Druckschritt her� Zuerst müssen Sie die Objekte mit Hilfe eines CAD-Programms erstellen und als *�stl, *�obj oder *�3mf abspeichern� Anschließend müssen Sie die SIMPLEX sliceware anwenden, um Ihre 3D-CAD-Dateien in Druckobjekte für den SIMPLEX 3D-Filament-Drucker umzuwandeln� Übertragen Sie Ihre Dateien über einen USB-Stick oder ein USB-Kabel auf Ihren SIMPLEX 3D-Filament-Drucker�...
► Haube und Tür haben eine Sicherheitsfunktion. Der Betrieb ohne Haube und/oder ohne Tür ist untersagt. ► Halten Sie das Netzkabel von heißen Oberflächen fern. ► Berühren Sie keine beweglichen Teile oder erhitzte Elemente, dies kann zu Verletzungen führen. ► Greifen Sie während des Druckvorgangs niemals in das eingeschaltete Gerät. Verschiedene Teile der Maschine (hauptsächlich der Extruder und das beheizte Druckbett) arbeiten bei sehr hohen Temperaturen und können schwere Verbrennungen verursachen. ► Stellen Sie vor Wartungsarbeiten sicher, dass das Gerät ausgeschaltet und das Netzkabel vom Netz getrennt ist. Warten Sie nach dem Herausziehen des Netzsteckers mindestens 5 Minuten, bis das Gerät abgekühlt ist, bevor Sie zur Wartung in den Drucker greifen. ► Schalten Sie den Drucker immer aus und trennen Sie ihn vom Computer, wenn Sie ihn nicht ver- wenden. ► Der SIMPLEX 3D-Filament-Drucker schmilzt während des Druckvorgangs Filamente aus Kunst- stoff. Während des Druckvorgangs werden plastische Gerüche / Gase freigesetzt. Stellen Sie sicher, dass der SIMPLEX 3D-Filament-Drucker an einem gut belüfteten Ort aufgestellt wird. ► SIMPLEX-Filamente verwenden, da diese beim Druckvorgang keine gesundheitsschädigende Gase entwickeln. ► SIMPLEX-Filamente sind nicht für die Anwendung im Mund des Patienten geeignet. ► Bei der Verwendung alternativer Filamente prüfen, dass während des Druckvorgangs keine ge- sundheitsschädigende Gase freigesetzt werden. Sicherheitsdatenblätter beachten. ► Bei der Verwendung von Filamenten, die ein Medizinprodukt sind, sind die eingestellten Parame- ter mit dem Filamenthersteller abzustimmen. ► Diese Einrichtung ist nicht für Verwendung an Orten geeignet, an denen möglicherweise Kinder anwesend sein können. 2.6 Zugelassene Personen Das Gerät darf...
⇒ Entnehmen Sie vorsichtig die mitgelieferte Zubehörbox, diese schützt den Extruder während des Trans- portes� Diese Box enthält das Zubehör für den SIMPLEX 3D-Filament-Drucker� ⇒ Heben Sie den SIMPLEX 3D-Filament-Drucker aus dem Versandkarton, indem Sie seitlich in den Rah- men greifen�...
Achtung: Kapton-Folie nicht beschädigen! ⇒ Entnehmen Sie die Tür, die sich unter dem Druckbett befindet. ⇒ Öffnen Sie den Karton mit der Haube vorsichtig, um den Inhalt nicht zu beschädigen. ⇒ Entnehmen Sie die Haube und legen Sie sie für den späteren Zusammenbau sicher ab� Zusammenbau des Druckers 4.2.1 Installieren des Filamentspulenhalters ⇒ Entfernen Sie die Schraube (31) an der Oberseite hinten mit Hilfe des mitgelieferten Inbusschlüssels� ⇒ Befestigen Sie den Filamentspulenhalter (7) mit der Schraube an dieser Position�...
Geräts mit Hilfe des mitgelieferten Inbusschlüssels� ⇒ Setzen Sie die Haube auf� ⇒ Schließen Sie den Lüfter an der Buchse (15) auf der Geräte- rückseite an� Achten Sie auch später darauf, dass der SIMPLEX ausge- schaltet ist, wenn Sie den Lüfter anschließen, da es sonst zu einem Kurzschluss kommen kann. Die Haube muss nicht zwingend mit den Schrauben wieder Abb. 6 befestigt werden.
Seite zurück zu gehen, eine Einstellung zu be- enden, einen Vorgang abzubrechen oder um das Hauptmenü wieder zu erreichen. Einstellen der Sprache Zu diesem Thema finden Sie ein Video über den folgenden Link www.renfert.com/simplex-2-de sowie über den abgebildeten QR-Code. ⇒ Wählen Sie das Menü EINSTEL� �...
� Eine Verbindung mit dem ausgewählten WLAN-Netzwerk konnte hergestellt werden: ♦ Der Name des verbunden WLAN-Netzwerks wird angezeigt Abb. 15 ♦ Die für den SIMPLEX 3D-Filament-Drucker vergebene IP-Adresse (LAN IP) wird angezeigt� Es konnte keine Verbindung mit dem ausgewählten WLAN-Netzwerk hergestellt werden: ♦ Eine Fehlermeldung wird angezeigt: „Keine Verbindung zum Host <Name des WLAN-Netzwerks>“ ⇒ Verwenden Sie den unteren Linkspfeil , bis Sie das Hauptmenü...
über den abgebildeten QR-Code. Der SIMPLEX verfügt über ein Nivellierungsverfahren welches sicherstellt, dass der Extruder und das beheizte Druckbett einen optimalen Abstand (0,3 mm) aufweisen und gleichmäßig nivelliert sind� Ein kleinerer Spalt oder eine ungleichmäßige Nivellierung kann zu einer Beschädigung der Kapton-Folie (orange-farbene Folie auf dem Druckbett), des Druckbetts, des Extruders oder zu Druckproblemen füh-...
, bis Sie das Hauptmenü wieder erreicht haben� Druckkopf manuell verfahren Zu diesem Thema finden Sie ein Video über den folgenden Link www.renfert.com/simplex-5-de sowie über den abgebildeten QR-Code. Für die folgenden Arbeitsschritte sollte der Druckkopf in eine günstige Position bewegt werden� ⇒ Wählen Sie das Menü ACHSEN �...
über den abgebildeten QR-Code. 5.6.1 Filament auswählen / Heizvorgang starten Zum Laden muss der Extruder auf Betriebstemperatur (= Drucktemperatur) vorgeheizt werden. Im SIMPLEX 3D-Filament-Drucker sind die Temperaturwerte für den Extruder (= Druck-Temp:) und das Druckbett (= Bett-Temp:) von vier unterschiedlichen Filamenten gespeichert. • TEMP1: SIMPLEX study model / working model / multi-use • TEMP2: SIMPLEX aligner model • USER1: freie Eingabe • USER2: freie Eingabe Wie Sie für die Filamente USER1 und USER2 eigene Temperaturwerte hinterlegen können, erfah- ren Sie in Kap.
Seite 18
⇒ Entfernen Sie das Filamentführungsrohr (2) aus der Öffnung oben am Extruder (10)� ⇒ Führen Sie das Ende des Filaments von unten durch den FMS in das Filamentführungsrohr ein, bis es auf der anderen Seite austritt� Achten Sie darauf, dass das Filament nicht von der Rolle springt oder sich verknotet. Das Filament muss sauber auf der Rolle aufgewickelt sein. Unsauber aufgewickelte oder verknotete Filamente können zu unsauberen Drucken oder sogar zu Fehldrucken führen.
Das FMS-System wird negativ beeinflusst und die Drucküberwachung ist fehlerhaft. 5.7.1 FMS-System kalibrieren Zu diesem Thema finden Sie ein Video über den folgenden Link www.renfert.com/simplex-7-de sowie über den abgebildeten QR-Code. Damit das FMS-System richtig arbeitet, muss es kalibriert werden� Durch die vorherigen Schritte ist der Extruder bereits aufgeheizt und das Filament wurde geladen�...
==> Filament TEMP2 5.8.1 Objekt von USB Stick laden ⇒ Schalten Sie den SIMPLEX aus (13)� ⇒ Stecken Sie den USB-Stick in den USB-Anschluss (11) am SIMPLEX ein� ⇒ Schalten Sie den SIMPLEX ein (13)� Abb. 34 ⇒ Wählen Sie das Menü USB �...
Im Folgenden werden weitere Optionen des Menüs EINSTELLUNGEN vorgestellt� 6.1 Datum/Uhrzeit einstellen / Betriebsstundenzähler zurücksetzen Zu diesem Thema finden Sie ein Video über den folgenden Link www.renfert.com/simpl-11-de sowie über den abgebildeten QR-Code. Sie können Datum/Uhrzeit einstellen und den Betriebsstundenzähler zurückset- zen� Diese Funktion hilft dabei, die Betriebsstunden zwischen den Wartungen zu verfolgen�...
Die Einstellung des Objektlüfters kann auch während des Druckvorgangs verändert werden. Im Renfert-Modus sind die Druckparameter für ein perfektes Druckergebnis hinterlegt. Alle not- wendigen Settings für den KFO-Bereich sind optimal konfiguriert und auf das Filament abge- stimmt. Diese sorgen für hohe Prozesssicherheit und Einfachheit. Werden die Lüftereinstellungen geändert, verändert man die vorinstallierten Parameter während eines Druckvorgangs.
Das WLAN-Modul ist ausschließlich als Informations-Tool zur Drucküber- wachung zu nutzen. Mit dem WLAN-Modul können keine Druckaufträge gestartet, pausiert oder gestoppt werden. SIMPLEX stellt ebenfalls ein WLAN als Host zur Verfügung� Um es verwenden zu können, nehmen Sie folgende Einstellungen vor: ⇒ Wählen Sie das Menü EINSTEL� �...
Bedienung 7.1 Gespeicherte Filamente Im SIMPLEX 3D-Filament-Drucker werden die Temperaturwerte für den Extruder (= Druck-Temp�) und das Druckbett (= Bett-Temp�) von vier unterschiedlichen Filamenten gespeichert� • TEMP1: SIMPLEX study model / working model / multi-use • TEMP2: SIMPLEX aligner model • USER1: freie Eingabe • USER2: freie Eingabe 7.2 Einstellen individueller Druck- und Betttemperatur Die Werte für die Filamente TEMP1 und TEMP2 sind optimiert und können nicht verstellt werden! Geändert werden können nur die Werte für die Filamente USER1 und USER2.
7.4 Laden des Filaments Zu diesem Thema finden Sie ein Video über den folgenden Link www.renfert.com/simplex-6-de sowie über den abgebildeten QR-Code. Die Vorgehensweise zum Laden eines Filaments finden Sie im Abschnitt „Erste Schritte“. 7.5 Extrudieren Zu diesem Thema finden Sie ein Video über den folgenden Link www.renfert.com/simplex-6-de...
Bewegen des Druckkopfs und des Druckbetts In dem Menü ACHSEN können Sie den Druckkopf und das Druckbett manuell beliebig bewegen oder automatisch in ihre Ausgangsposition (Home) fahren� Achten Sie darauf, das bei Fahrten in die Ausgangsposition keine Objekte auf dem Druckbett vor- handen sind. Die Ausgangsposition des Druckkopfs befindet sich in der vorderen linken Ecke der Bauplatte. Die Ausgangsposition des Druckbetts befindet sich in der obersten Position. ⇒ Wählen Sie das Menü ACHSEN � Ausgangspositionen anfahren ⇒...
Sie bei der Installation der Software Probleme haben, wenden Sie sich bitte an den Renfert Service unter Support@renfert.de. ⇒ Installieren Sie die Renfert CONNECT App aus dem App Store (Apple) oder dem Google Play Store (Android) auf Ihrem mobilen Endgerät� ⇒ Öffnen Sie die App und melden Sie sich mit einem bereits bestehenden Account an (Anmelden) oder erstellen Sie sich für Ihr Labor / Ihre Praxis einen Renfert Account (Registrieren)�...
Das Programm SIMPLEX sliceware erhalten Sie über die Renfert CONNECT App (siehe Kap. 9) Den erzeugten G-Code können Sie mit dem Programm SIMPLEX print über ein USB-Kabel an den Drucker senden und ausdrucken, oder auf einen USB Stick kopieren und darüber einen Ausdruck erstellen�...
Settings für den KFO-Bereich sind optimal konfiguriert und auf das Filament abgestimmt. Diese sorgen für hohe Prozesssicherheit und Einfachheit. Werden diese Einstellungen geändert, verändert man die vorinstallierten Parameter. Renfert übernimmt in diesem Fall keine Garantie für die Qualität des Drucks.
Abb. 62 figuriert und auf das Filament abgestimmt. Diese sorgen für hohe Prozess- sicherheit und Einfachheit. Werden diese Einstellungen geändert, verändert man die vorinstallierten Parameter. Renfert übernimmt in diesem Fall keine Garantie für die Qualität des Drucks. Beleuchtung / Helligkeit des Displays: Ändern der Helligkeit der Hintergrundbeleuchtung des Displays�...
Warten und Ölen Sie die empfohlenen Teile so oft wie in Abschnitt Reini- gung empfohlen. Verwenden Sie nur die von Renfert empfohlenen War- tungsmaterialien. 11.1 Reinigung ⇒ Reinigen Sie das Gehäuse und die Haube des SIMPLEX 3D-Filament-Druckers mit einem feuchten Tuch� Reinigung des Druckbetts: ⇒ Fahren Sie das Druckbett in eine für die Reinigung vorteilhafte Position (Menü ACHSEN ), Kap� 7)� ⇒ Reinigen Sie das Druckbett ausschließlich mit Glasreiniger auf Spiritusbasis oder reinem Alkohol und wischen Sie es mit einem trockenen Tuch oder einem Papiertuch ab�...
11.2.1 Schmierung der Z-Achse Führungs- und Gewindestange der Z-Achse befinden sich im Innenraum des Druckers an der Rückseite. ⇒ Wählen Sie das Menü ACHSEN (Abb� 9)� ⇒ Fahren Sie den Druckkopf und das Druckbett in die Ausgangsposition ⇒ Drucker ausschalten und Netzstecker ziehen� ⇒ Schieben Sie ein gefaltetes Papiertuch oder einen fusselfreien Lappen zwischen die Gewindestange und die Rückwand, um andere Bereiche des Druckers vor eventuell auftretendem Übersprühen zu schützen�...
Es ist besonders wichtig, zwischen der Verwendung verschiedener Filamente alte Filamentreste zu entfernen. Die unterschiedlichen Filamenteigenschaften (selbst das Drucken des gleichen Materials in einer anderen Farbe) können zu Verstopfungen aufgrund von Inkonsistenzen führen. Schalten Sie den SIMPLEX 3D-Filament-Drucker erst ab, wenn die Düsen abgekühlt ist (< 60°C). (Hinweis: Extruder-Lüfter schaltet sich ab, bei < 60°C ). Schalten Sie den SIMPLEX 3D-Filament- Drucker bei heißem Extruder ab, kann die Temperatur aus dem Extruder ins Heatbreak ausbreiten, das Filament schmelzen und nach Erkalten des Extruders zu einer Verstopfung führen. Eine Verstopfung des Extruders können Sie mit dem kleinsten der mitgelieferten Inbusschlüssel beseiti- gen�...
⇒ Lösen Sie die versenkte Schraube hinter der Düse um ca� 2 Umdrehungen� Abb. 70 ⇒ Ziehen Sie den Temperatursensor und die Heizpatrone gerade nach hinten heraus� Abb. 71 ⇒ Lösen Sie die zwei Schrauben am Kühlkörper und ziehen Sie die Düseneinheit nach unten heraus�...
11.6 Firmware - Update Ein Firmware-Update erhalten Sie ausschließlich über die Renfert CONNECT App (siehe Kap� 9)� Mit der Renfert CONNECT App wird sichergestellt, dass Sie über den neusten Stand der Firmware infor- miert werden� Eine neue Firmware verbessert die Leistungsfähigkeit des SIMPLEX 3D-Filament-Druckers und sollte immer über das Update installiert werden�...
⇒ Schalten Sie den Drucker wieder ein und warten Sie, bis das Update abgeschlossen ist ⇒ Wenn das Update abgeschlossen ist, schalten Sie den Drucker aus und wieder ein� ⇒ Überprüfen Sie die SIMPLEX Firmware-Version auf dem Drucker� 11.7 Pufferbatterie wechseln Der Wechsel der Pufferbatterie darf nur von einer elektrotechnischen Fachkraft oder gleichwertig qualifizierten Person durchgeführt werden.
• Stecker komplett einstecken� Fataler Fehler! richtig gesteckt� • Nur im ausgeschalteten Zustand einstecken� Kurzschluss auf der 12 V- Leitung! Spule deckt den An- • Spule zu groß� • Kleinere Spule verwenden� Renfert Filament verwen- schluss für den Filament- den� sensor (RJ45 Buchse) ab. Datum / Uhrzeit ist ver- • Pufferbatterie der Uhr ist entladen. • Pufferbatterie wechseln (siehe Kap. 11.7). stellt. FMS System meldet einen •...
Seite 38
• Erneute Betrachtung der Situation in der CAD-Software� ausgerichtet� Nach Bedarf muss die Ausrichtung in der CAD-Software Ursache liegt nicht bei der korrigiert werden, bevor die STL-Datei mit der SIMPLEX SIMPLEX sliceware� sliceware erneut gesliced wird� SIMPLEX sliceware kann die Aus- richtung des Modells nicht beein- flussen.
Störungen Ursache Abhilfe Die ersten Schichten hal- • Modell wurde in der SIMPLEX • Auf richtiges Absetzen der Modelle achten� ten nicht ordentlich am sliceware nicht plan auf dem virtu- • Beim Vergrößern, darf kein Zwischenraum zwischen Druckbett und lösen sich.
14 Garantie Bei sachgemäßer Anwendung gewährt Renfert Ihnen auf alle Teile des Gerätes eine Garantie von 3 Jahren� Voraussetzung für die Inanspruchnahme der Garantie ist das Vorhandensein der Original-Verkaufsrech- nung des Fachhandels� Ausgeschlossen aus der Garantieleistung sind Teile, die einer natürlichen Abnutzung ausgesetzt sind (Verschleißteile) sowie Verbrauchsteile�...
Seite 41
SIMPLEX 3D-Filament-Drucker Made in Germany...
Seite 42
6.1 Setting the date/time / resetting the operating hours meter ���������������������������������������������������������������������������������������������������������������������� 6�2 Setting the display backlight ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 6�3 Activating the fan ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 6�4 Audio settings ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 6�5 The cover menu ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 6.6 Using the SIMPLEX Wi-Fi ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 6.7 The FMS system ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 6�8 Resetting settings �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Operation �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 7.1 Saved filaments ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 7�2 Setting a custom print and bed temperature ������������������������������������������������������������������������������������������������������������������������������������������������������������...
Seite 43
8 Moving the print head and the print bed ������������������������������������������������������������������������������������������������������������������������������������������� 9 Renfert CONNECT app ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 9.1 Installing SIMPLEX sliceware / SIMPLEX print ����������������������������������������������������������������������������������������������������������������������������������������������������� 10 Printing objects ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 10.1 Printing using a USB flash drive ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 10�2 Actions during USB printing ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 10�2�1 Stop ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 10.2.2 Settings / optimization ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 10.2.3 Pause next layer ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 10�2�4 Pause �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 10.3 Printing with SIMPLEX print ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 11 Cleaning / Maintenance ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 11�1 Cleaning ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������...
Introduction General description Congratulations on the purchase of your SIMPLEX 3D filament printer and welcome to the world of 3D printing! The SIMPLEX 3D filament printing system was developed by Renfert with the goal of simplifying and perfecting the 3D printing process with filaments. It offers an excellent manufacturing experience without the need for prior knowledge of programming or 3D printing. To print a 3D object, you need the SIMPLEX 3D filament printer, SIMPLEX sliceware, and a SIMPLEX filament of your choice. "App Store", "Apple", "Google", "Play Store", and "Android" are registered trademarks of Apple or Google� Symbols used Symbols with the following meanings are used in these instructions or on the equipment: Danger Immediate danger of injury.
USB cable� Improper use Only spare parts and accessories supplied or authorized by Renfert GmbH may be used with this prod- uct. If other spare parts or accessories are used, this could have a detrimental effect on the safety of the equipment, increase the risk of serious injury and lead to damage to the environment or the product itself�...
Ensure that the SIMPLEX 3D filament printer is placed in a well-ventilated location. ► Use SIMPLEX filaments, as they do not result in any gases during printing that are harmful to health. ► SIMPLEX-filamente are not suitable for the application in the patients mouth ►...
Product description Assemblies and functional elements 12 USB B port for connection to a PC Touchscreen LCD display / main menu Filament guiding tube 13 ON/OFF switch / connection for mains power supply Nozzle 14 Port for filament sensor Removable glass plate 15 Port for cover fan Leveling knobs 16 Distance card Z-Axis rod 17 Menu - TEMPERATURE Filament spool holder Filament spool 18 Menu - EXTRUDER...
Please note the weight of the printer and ask a second person to assist you if necessary. When removing, be careful not to touch the extruder and the electronics. The SIMPLEX 3D filament printer is not suitable for setup in the treatment room. ⇒ Place the SIMPLEX 3D filament printer on a stable and level surface with sufficient space around the unit�...
Printer assembly 4.2.1 Installing the filament spool holder ⇒ Remove the screw (31) on the top rear using the Allen key pro- vided� ⇒ Secure the filament spool holder (7) with the screw in this posi- tion� Fig. 2 4.2.2 Installing the filament sensor (FMS) ⇒ Remove the screw (30) on the top rear using the Allen key pro- vided� ⇒ Secure the FMS (9) with the screw in this position. ⇒ Plug the FMS connection cable into the rear of the unit (14). Fig. 3 Fig. 4 4.2.3 Installing the filament guiding tube ⇒ Insert one end of the filament guiding tube (2) into the FMS (9) from above�...
Allen key provided� ⇒ Place the cover into position� ⇒ Connect the fan to the socket (15) on the rear of the unit. Also ensure subsequently that the SIMPLEX unit is switched off when you connect the fan as otherwise a short circuit could occur. The cover does not necessarily have to be secured again with the screws.
Setting the language A video on this topic is provided under the following link www.renfert.com/simplex-2-en and via the QR code shown. ⇒ Select the SETTINGS menu. �...
⇒ Enter the password of the selected Wi-Fi network. ⇒ Confirm the password using the checkmark � A connection was successfully established to the selected Wi-Fi network: ♦ The name of the connected Wi-Fi network is shown ♦ The IP address (LAN IP) allocated for the SIMPLEX 3D filament printer is shown� A connection could not be established to the selected Wi-Fi network: Fig. 15 ♦ An error message is shown: "No connection to host <Name of the WiFi network>"...
Seite 53
Leveling the print bed A video on this topic is provided under the following link www.renfert.com/simplex-4-en and via the QR code shown. The SIMPLEX unit features a leveling process that ensures that the extruder and heated print bed are optimally spaced (0.3 mm) and leveled uniformly. A smaller gap or uneven leveling can result in damage to the Kapton film (orange colored tape on the print bed), the print bed, the extruder, or in printing issues. The gap between the extruder and the print bed is set using three adjustment screws under the print bed: The print bed should be leveled after initial installation and approx. 1x every month.
Moving the print head manually A video on this topic is provided under the following link www.renfert.com/simplex-5-en and via the QR code shown. The print head must be moved to an appropriate position for the following steps�...
Ensure that the filament spool is placed on the filament spool holder in such a way that the filament can be inserted clock- wise into the FMS from underneath (Fig. 20). Only use Renfert filaments, as they do not result in any gases during printing that are harmful to health. If using alternative filaments, ensure that no gases are re- leased during printing that are harmful to health.
Seite 56
⇒ Remove the filament guiding tube (2) through the opening on top of the extruder (10). ⇒ Insert the end of the filament from underneath through the FMS into the filament guiding tube until it exits on the other side. Ensure that the filament does not spring off the spool or become tangled. The filament must be neatly wound on the spool. Improperly wound or knot- ted filaments can lead to printing errors or even misprints. Fig. 23 Fig. 24 ⇒ Move the lever at the top of the extruder to the left (Fig. 25). Fig. 25 Fig. 26 Fig. 27 ⇒ Push the filament through the top opening of the extruder until the filament is between the two guide wheels (Fig. 26). ⇒ Now move the lever of the extruder to the right (Fig. 27) ⇒ Ensure that the filament is held by the two guide wheels by gently pulling on the filament and feeling resistance� ⇒ Heating of the extruder was already started in the previous step. ♦ The head temperature is shown in white in the TEMPERATURE menu. ⇒ Wait until "Ready to print" is shown in the TEMPERATURE menu. ⇒ Select the EXTRUDER menu� Fig. 28 If you select the EXTRUDER menu too early and the extruder has not yet reached the required temperature, a warning message is shown�...
The FMS system is negatively impacted, and printing is not correctly monitored. 5.7.1 Calibrating the FMS system A video on this topic is provided under the following link www.renfert.com/simplex-7-en and via the QR code shown. The FMS system must be calibrated in order for it to operate correctly. As a result of the previous steps, the extruder is already heated up and the filament is loaded.
The following G-codes are available: G-Code SIMPLEX study model, working model, multi-use model ==> Filament TEMP1 G-Code SIMPLEX aligner model ==> Filament TEMP2 5.8.1 Loading an object from a USB flash drive ⇒ Switch off the SIMPLEX unit (13). ⇒ Insert the USB flash drive into the USB port (11) on the SIMPLEX unit. ⇒ Switch on the SIMPLEX unit (13). Fig. 34 ⇒ Select the USB menu� ⇒ Use the arrows to select the file name of the object.
• Calibrating an FMS system. Additional options in the SETTINGS menu are presented below. Setting the date/time / resetting the operating hours meter A video on this topic is provided under the following link www.renfert.com/simpl-11-en and via the QR code shown. You can set the date/time and reset the operating hours meter. This function helps you to track operating hours between maintenance work�...
60 °C [140 °F]. The extruder and case fans are automatically switched off again after 60 seconds. Fig. 43 The setting of the object fan can also be modified during printing. In Renfert mode, the printing parameters are stored for a perfect printing result. All of the nec- essary settings for orthodontic applications are optimally pre-configured and tailored to the filament. This ensures a high level of process reliability and simplicity. If the fan settings are changed, the pre-installed parameters are modified during printing. This can impair print quality, cause misprints, or cause damage to the printer.
Using the SIMPLEX Wi-Fi The Wi-Fi module is only available in EU member states and in the USA. The button with the Wi-Fi icon can only be operated if the Wi-Fi module is available. The Wi-Fi module may only be used as an information tool for monitoring printing.
Operation Saved filaments The temperature values f or the extruder (= head temp:) and the print bed (= bed temp:) of four different filaments are stored in the SIMPLEX 3D printer. • TEMP1: SIMPLEX study model / working model / multi-use • TEMP2: SIMPLEX aligner model • USER1: Freely configurable • USER2: Freely configurable Setting a custom print and bed temperature The values f or the TEMP1 and TEMP2 filaments are optimized and cannot be adjusted! Only the values for the USER1 and USER2 filaments can be changed. The temperatures set here only apply for loading/unloading the filament and for manual extrusion. When printing a model, the temperatures stored in the G-code of the model are used.
Loading the filament A video on this topic is provided under the following link www.renfert.com/simplex-6-en and via the QR code shown. The procedure for loading a filament can be found in the "Getting Started" section. Extrusion A video on this topic is provided under the following link www.renfert.com/simplex-6-en and via the QR code shown.
Moving the print head and the print bed In the AXES menu, you can manually move the print head and the print bed as required or automatically move them to their home position� Ensure that there are no objects on the print bed when moving to the home position. The home position of the print head is in the front left corner of the build plate� The home position of the print bed is the uppermost position�...
Renfert CONNECT app Using the Renfert CONNECT app you can download the SIMPLEX sliceware and SIMPLEX print pro- grams and install them on your computer as well as obtain firmware updates for your SIMPLEX 3D filament printer. If there is no mobile device available you can install the Renfert CONNECT App to, or you encoun- ter problems during installation, please contact the Renfert service under Support@renfert.de. ⇒ Install the Renfert CONNECT app from the App Store (Apple) or the Google Play Store (Android) on your mobile device� ⇒ Open the app and log in with an existing account, or register to create a Renfert account for your labo- ratory / dental office. ⇒ Go to "My Equipment". ⇒ Select "Add device"� ⇒ Select "SIMPLEX" as the device type. ⇒ Enter the serial number of your printer.
Ensure that the print bed has been correctly leveled before printing (see Chap. 5.4). If you use a different filament for printing than for the previous print object, you must recalibrate the FMS system (see Chap. 5.7.2). 10.1 Printing using a USB flash drive ⇒ Connect the USB flash drive to your PC. ⇒ Save the G-code generated with SIMPLEX sliceware on the USB flash drive provided. The file name must not contain any special characters or umlauts. These cannot be read by the printer. Printing cannot be started, and an error message is shown� ⇒ Switch off the SIMPLEX unit (ON/OFF switch 13, Fig. 1). ⇒ Insert the USB flash drive into the USB port (11, Fig. 1) on the SIMPLEX unit. ⇒ Switch on the SIMPLEX unit (ON/OFF switch, 13, Fig. 1).
• Object fan control • FMS settings Changes you make here overwrite the settings in the G-code� Caution! In Renfert mode, the printing parameters are stored for a perfect printing result. All of the nec- essary settings for orthodontic applications are optimally pre-configured and tailored to the filament. This ensures a high level of process reliability and simplicity. Changing these settings modifies the pre-installed parameters. In this case, Renfert does not guarantee printing quality. - 27 -...
Printing speed / flow rate: The printing speed and extrusion volume can be changed as a percentage of the original� Use the reset button to return to the G-code values� Caution! In Renfert mode, the printing parameters are stored for a perfect printing result. All of the necessary settings for orthodontic applications are opti- mally pre-configured and tailored to the filament. This ensures a high level Fig. 62 of process reliability and simplicity. Changing these settings modifies the...
Allow the SIMPLEX unit to cool down for at least 30 minutes before cleaning and maintenance work. Only carry out cleaning and maintenance work on the SIMPLEX unit if it has been switched off. After 1,000 hours of operation, the printer must be cleaned, and used and worn parts in the printer replaced.
11.2.1 Lubrication of the z-axis The guide rod and threaded rod of the z-axis are located inside the printer at the rear. ⇒ Select the AXES menu (Fig. 9). ⇒ Adjust the print head and the print bed to the home position � ⇒ Switch off the printer and disconnect the power plug. ⇒ Slide a folded paper towel or lint-free cloth between the threaded rod and the back to protect other areas of the printer from any overspray that may occur�...
11.3 Unblocking the extruder A blocked extruder is the most common problem with any 3D filament printer and cannot be prevented entirely� When loading/unloading the filament, a blockage can often be avoided by waiting until the extruder has reached the temperature corresponding to the filament. It is especially important to remove old filament residue between using different filaments. Different filament properties (even printing the same material in a different color) can cause block- ages due to inconsistencies. You can clear a blockage in the extruder with the smallest of the Allen keys provided. Caution! Danger of burns! The blockage must be cleared while the print head / extruder is hot. Wear protective gloves! ⇒ If you have not already done so, remove the filament (see Chap. 7.6). ⇒ Move the lever at the top of the extruder to the left. ⇒ Heat the extruder to 250 °C. ⇒...
⇒ Loosen the countersunk screw behind the nozzle by approx. 2 turns� Fig. 70 ⇒ Pull the temperature sensor and heater cartridge out towards the back in a straight line� Fig. 71 ⇒ Loosen the two screws on the heat sink and pull the nozzle unit out downwards� Only loosen the screws, to not unscrew them! Fig.
You will receive a link to the mail adresse, stored during your registration ⇒ Open the mail with a mail client on your computer� ⇒ Click on the link in the mail� ⇒ Download the firmware ZIP file to your computer and extract it. ⇒ Read the release notes provided� ⇒ Connect the SIMPLEX 3D filament printer with the USB A-B cable (see Chap. 3.2 Scope of delivery) to your computer� ⇒ Open the SIMPLEX print program. ⇒ In the "..." menu, select the option "Load custom firmware from file". ⇒ Select the *.firmware file and open it. ⇒ Click OK in the message to confirm that the firmware was loaded successfully.
⇒ screw on the upper panel� Fig. 77 11.9 Spare parts You can find wear parts and spare parts in the spare parts list available online at www.renfert.com/p918� Enter the following item number: 17350000. The components excluded from the warranty (wear parts, consumables) are marked in the spare parts list� The serial number, date of manufacturing and equipment version are shown on the nameplate of the equipment�...
• Model misaligned in CAD software. • Review the situation in the CAD software� If necessary, correct angle. The SIMPLEX sliceware is not the the orientation must be corrected in the CAD software cause� before the STL file is sliced a gain with the SIMPLEX SIMPLEX sliceware cannot influ- sliceware� ence the orientation of the model� - 35 -...
Seite 76
• When enlarging, a gap should not be visible between the bed and loosen. sliceware. Model has little contact model and the print bed. The model must be placed flat Unwanted lines are with the print bed and therefore and fitted on the virtual print bed. shown on the underside. insufficient adhesion. • Tip: Use "Drop" in Renfert mode� • - 36 -...
Nozzle diameter 0�4 mm Printing speed 50 - 200 mm/s Number of extruders Single Type of extruder All-metal hotend Nozzle operating temperature 180 - 260 °C / [356 - 500 °F] Operating temperature of the build plate 50 - 110 °C / [122 - 230 °F] Ambient temperature 15 - 32 °C / [59 - 90 °F] Storage temperature 0 - 32 °C / [32 - 90 °F] Software Software package SIMPLEX sliceware / SIMPLEX print File types OBJ / STL / CWPRJ Supported systems Windows 7 and higher, OS X, Linux - 37 -...
14 Warranty Renfert offers a 3-year warranty on all parts of the equipment, provided that the equipment is properly used� Warranty claims may only be made upon presentation of the original sales receipt from the authorized dealer� Parts which are subject to natural wear and tear (wear parts) and consumables are excluded from the warranty� These parts are marked in the spare parts list� The warranty is voided in the case of improper use; failure to observe the operating, cleaning, mainte- nance, and connection instructions;...
EG-Konformitätserklärung EC Declaration of conformity Renfert GmbH, Industriegebiet, 78247 Hilzingen / Germany Renfert GmbH, Industriegebiet, 78247 Hilzingen / Germany Hiermit erklären wir, dass das Produkt Herewith we declare that the product SIMPLEX 3D Drucker SIMPLEX 3D Drucker allen einschlägigen Bestimmungen der folgenden Richtlinien...
