D
(A) Carrying handle
(B) Vertical adjustment (locking bolt)
(C) Connecting line with mains plug
(D) Bracket
(E) Cable winding (only RAPTOR PRO RP LED)
(F) Standing foot (only RAPTOR PRO RP LED)
(G) Standing bracket
(H) Star grip
The ALDEBARAN® RAPTOR RP / PRO LED is delivered ready for connection with supply cable and plug. The LED spotlight
is only to be connected to an alternating current – with the voltage according to the rating plate – to a properly installed
safety socket. Please note that your system corresponds to the relevant VDE guidelines.
If you have any questions about this, please contact your energy supplier or your electrician. Of course we are at your
disposal if you have any questions.
ATTENTION!
In the case of versions of the LED spotlight with other plug-in systems (not Schuko®), the voltage according to the
rating plate must be observed.
By means of a bracket (D), the ALDEBARAN® RAPTOR RP / PRO LED can be mounted directly on site for many applications.
Mounting holes are provided for this purpose.

Controls

A
B
B
C
C
F

Initial operation

Installation

H
G
A
E
13
