1. Connect the black probe to terminal COM and the red probe to terminal VΩmA
2. Set the function switch to the desired AC voltage rating
3. Connect the test plungers to the circuit and read the value displayed on
screen once it has stabilised.
1. Connect the black probe to terminal COM and the red probe to terminal VΩmA
2. Set the function switch to the desired DC voltage rating
3. Connect the test plungers to the circuit and read the value displayed on
screen once it has stabilised. When measuring DC voltage, the display shows
the polarity of the red probe.
1. Connect the black probe to terminal COM and the red probe to terminal VΩmA
2. Set the function switch to the desired DC direct current rating
3. Connect the test plungers to the circuit and read the value displayed on
screen once it has stabilised.
1. Connect the black probe to terminal COM and the red probe to terminal VΩmA
2. Set the function switch to the desired resistance rating
3. Connect the test plungers to the circuit and read the value displayed on
screen once it has stabilised.
1. Connect the black probe to terminal COM and the red probe to terminal VΩmA
2. Set the function switch to position
3. The buzzer will sound if the resistance is ≤30Ω.
